Panduit FRXTL77Y001M020 OM3 12-Fiber MPO Trunk Cable

The Panduit FRXTL77Y001M020 is a 20-meter OM3 multimode trunk cable engineered for high-density structured cabling deployments in enterprise datacenters, telecommunications rooms, and distribution frames. Pre-terminated with 12-fiber MPO female connectors on both ends, this Opti-Core® assembly eliminates field splicing and reduces installation time by up to 80% compared to traditional break-out or fusion-splice methods. The 50/125µm OM3 fiber supports 10GBASE-SR Ethernet to 300 meters and 40GBASE-SR4 to 100 meters, making it the minimum-spec backbone for converged IP surveillance, access control, and building automation networks running over fiber infrastructure.

Key Features

• Pre-terminated MPO-to-MPO trunk — factory-terminated female MPO connectors both ends eliminate field labor, fusion-splice equipment, and termination errors in high-bay or raised-floor installs
• OM3 50/125µm multimode fiber — 10 Gbps to 300m, 40 Gbps to 100m, 100 Gbps to 100m with parallel optics; sufficient for IP camera aggregation switches, NVR uplinks, and core-to-distribution fiber runs
• 12-fiber count in single trunk — supports 6 duplex LC connections via MPO-to-LC breakout cassettes or fanouts; consolidates patch panel density and reduces cable-tray congestion in overhead or underfloor pathways
• Low Smoke Zero Halogen (LSZH) jacket — meets plenum-equivalent fire safety in EU and APAC installations; reduces toxic gas emission and corrosive halogen release in enclosed or below-grade telecom spaces
• 20-meter (65.6 ft) length — factory-measured length specification eliminates field cut-to-length and allows deterministic loss-budget calculations for TIA-568.3-D link certification
• TIA-568.3-D and ISO/IEC 11801 compliant — tested to ANSI/TIA-942-B datacenter standards for insertion loss, return loss, and polarity; includes factory test report with serial-number traceability

The FRXTL77Y001M020 addresses the core structured-cabling problem in modern IP security installations: high port-count aggregation between equipment racks. A typical 48-camera zone with PoE+ edge switches feeding a centralized NVR cluster requires 12–24 fiber strands for redundant 10 Gbps uplinks. Running individual duplex LC jumpers creates cable-tray chaos and introduces 24+ connector-pair insertion points where dirt, damage, or misalignment can break the link. The MPO trunk consolidates 12 fibers into a single ~8mm diameter cable with two hardened push-pull connectors, reducing both pathway fill and failure modes. Pair this trunk with Panduit FAP or FPIC MPO-to-LC cassettes in your patch panel, and the entire backbone becomes a plug-and-play operation — no fusion splicer, no field polish, no OTDR to hunt for bad terminations.

OM3 is the practical floor for new datacenter builds and IP security backbone deployments. While OM4 and OM5 offer longer 40/100 Gbps reach, the 100-meter OM3 spec covers 95% of intra-building horizontal and riser distances at a lower material cost. For integrators running 10GBASE-SR today with a migration path to 40 Gbps in 3–5 years, OM3 delivers the performance without the OM4 price premium. The LSZH jacket is mandatory in many European and Asian markets and increasingly specified in U.S. installations where plenum-rated cable costs and availability are concerns. LSZH does not replace plenum rating under NEC — verify local AHJ requirements — but it provides equivalent flame spread in EN 50399 (Euroclass) testing and eliminates the hydrochloride acid byproduct that corrodes copper and active electronics during fire events.

Installation is mechanical: route the trunk through cable tray or innerduct, plug the female MPO into the mating male adapter or cassette, verify polarity (Type-B is straight-through by default, verify with your cassette pinout), and certify the link with a Tier-1 or Tier-2 tester per TIA-568.3-D Annex B. The factory-terminated connectors ship with dust caps and survive typical rough handling during pull — the MPO housing is impact-rated and the boot strain relief is molded directly to the cable jacket. Panduit Opti-Core trunks include a serialized test report showing <0.35 dB insertion loss per mating pair, well under the 0.75 dB TIA budget, leaving headroom for cassette insertion and patch-cord loss in the permanent link.

This trunk is TIA-568.3-D and ISO/IEC 11801 compliant, tested to ANSI/TIA-942-B datacenter standards, and ships with Panduit's standard commercial warranty. For integrators building TIA-942 Rated-3 or Rated-4 datacenters, high-density IP surveillance control rooms, or enterprise telecom closets with 10 Gbps or faster aggregation requirements, the FRXTL77Y001M020 is the deterministic answer: known length, known loss, known polarity, zero field termination risk.
