Middle Atlantic NM 90 D. Flat Elbow PN05 - PN05F11V

Middle Atlantic PN05F11V Eclipse PN05 Non-Metallic Flat 90° Elbow Fitting

Overview

The PN05F11V is a flat 90-degree elbow fitting designed for use with Middle Atlantic's Eclipse PN05 non-metallic raceway system. This fitting solves the specific problem of making clean, right-angle horizontal direction changes in surface-mounted cable management runs — the kind of transition needed when routing cables around corners on walls or along baseboards without cutting or improvising field bends. The ivory finish integrates with standard commercial interior environments. TAA-compliant, making the PN05F11V eligible for U.S. government and federally funded projects where Trade Agreements Act compliance is required.

Compatibility

Designed exclusively for the Middle Atlantic Eclipse PN05 non-metallic raceway series. Verify that your installed raceway matches the PN05 profile before ordering — this elbow is sized and keyed to that specific channel width and snap-fit geometry. It will not interchange with Middle Atlantic's other raceway families (PN10, PN20, or metallic Eclipse series) or with third-party cable management raceways. If you are working with a different PN-series width, match the elbow part number to that channel size accordingly.

Installation Notes

This is a raceway fitting — no tools required for the fitting itself; it snaps or clips into the PN05 base channel per standard Eclipse installation practice. Confirm the base channel is secured to the wall surface before fitting corners. The flat elbow geometry is for in-plane horizontal turns only; use a different fitting variant for inside or outside vertical transitions.
