APC by Schneider Electric Netshelter SX 48U 1070MM Deep Split Side Panels Black QTY 2 - AR7371

APC by Schneider Electric AR7371 NetShelter SX 48U 1070mm Deep Split Side Panels — Black, Qty 2

Overview

The AR7371 delivers a matched pair of split side panels purpose-built for the APC NetShelter SX 48U enclosure with a 1070mm depth. If you're closing out an open-frame NetShelter SX rack for physical security, cable management aesthetics, or airflow containment, these panels provide the OEM fit that aftermarket sheet metal rarely matches. Supplied in black to coordinate with standard NetShelter SX cabinetry, the AR7371 ships as a quantity-two set — both sides addressed in a single order.

Key Features

• OEM fit for NetShelter SX 48U / 1070mm: Designed specifically for the 1070mm deep variant of the 48U NetShelter SX frame. Generic panels frequently require field modification; these mount without drilling or shimming, keeping your installation clean and your warranty intact.
• Split-panel design: The split format means you can route cables mid-panel without removing the full side — useful in live environments where downtime for cable work isn't an option.
• 32 lb / 14.55 kg pair: At roughly 16 lb per panel, these are substantial steel assemblies — plan for two-person handling during installation, particularly in overhead or confined-aisle deployments.
• Black finish — RAL-matched to NetShelter SX: Color consistency matters in customer-facing server rooms and co-location spaces. The AR7371 matches the standard NetShelter SX black finish rather than approximating it.
• Non-rack-mountable — frame-attached only: These panels attach directly to the NetShelter SX frame, not to rack rail. They're not universally compatible with other cabinet brands — verify your enclosure model before ordering.

Compatibility

The AR7371 is designed for the APC NetShelter SX 48U enclosure series with 1070mm internal depth. If your NetShelter SX has a different depth (600mm or 800mm are common variants), you'll need the corresponding panel SKU for that depth. Confirm your enclosure's depth rating on the cabinet label before ordering — APC depth designations are stamped on the frame rail near the base.

Explore the broader APC by Schneider Electric catalog for compatible accessories, power distribution units, and cooling solutions for the NetShelter platform.

Installation Notes

Panels ship as a pair and attach to the NetShelter SX side-panel mounting channels using the existing hardware provisions on the frame. No additional fasteners are typically required for standard NetShelter SX frames. Factor in roughly 37.64 inches (95.6 cm) of clear vertical space per panel when staging the install — these are full-height assemblies for a 48U cabinet.

For rack enclosure accessories including blanking panels, roof assemblies, and cable management, see the full enclosure accessories section.

Frequently Asked Questions

Q: What enclosure is the AR7371 compatible with?

A: The AR7371 is designed for the APC NetShelter SX 48U enclosure with 1070mm depth. It is not designed for other depths or other NetShelter product lines.

Q: How many panels are included in the AR7371?

A: The AR7371 ships as a quantity-two set — one left and one right split side panel.

Q: What is the weight of the AR7371?

A: The pair weighs 32.08 lb (14.55 kg). Plan for two-person handling during installation.

Q: Are the AR7371 panels rack-mountable in a standard EIA rail system?

A: No. The AR7371 panels are frame-attached only and are not rack-mountable on standard EIA rails. They attach directly to the NetShelter SX cabinet structure.

Q: What color are the AR7371 panels?

A: Black, matched to the standard APC NetShelter SX finish.

Marty Allison

When we spec out a NetShelter SX 48U deployment — particularly in co-location or secured IDF closets — the AR7371 side panels are frequently the last line item added and the first thing noticed if missing. The 1070mm depth designation is the key detail here: this panel is cut to the deeper 1070mm variant, and swapping in an 800mm panel results in a gap at the rear that defeats the purpose of closing the cabinet.

Technical Highlights:

• 1070mm depth match: Covers the full depth of the deeper NetShelter SX variant — the 37.64-inch panel height corresponds to a 48U frame, so there's no exposed gap top or bottom when installed correctly.
• Split construction: Allows mid-panel cable ingress without full panel removal — reduces scheduled maintenance windows in live rack environments where uptime commitments are tight.
• 32.08 lb pair weight: Heavier than typical sheet-metal aftermarket panels — indicator of gauge and finish quality, but also a logistics note: two-person lift is the right call, especially when working above floor height in a raised-floor data center.

Deployment Considerations:

• Confirm your NetShelter SX cabinet depth before ordering — the 1070mm depth is less common than the 600mm and 800mm variants, and APC uses different panel SKUs for each. The depth is labeled on the cabinet frame near the base.
• The AR7371 is frame-attached, not rail-mounted — it will not fit competing cabinet brands even if they share similar external dimensions. This is an OEM-only accessory.

Best fit: data center and IDF deployments running the 1070mm NetShelter SX where physical security policy or airflow containment requires a closed-cabinet configuration — not a universal panel kit.
