Vertiv I10405 Metered Upgradeable 30A Vertical Rack PDU
Overview
The Vertiv I10405 is a 70-inch vertical rack power distribution unit from the PowerIT rPDU line — model number MN01D4W1-36MR99-3TL14A0A10-S — designed for dense server environments where knowing exactly how much power each circuit is drawing is the difference between a clean deployment and an after-hours outage. With 36 total outlets, input and breaker-level current monitoring, and a local LED display, this unit gives data center and IT teams real-time visibility without requiring a full remote monitoring card out of the box. It runs at 30A/208V (5.7kW) from a single NEMA L14-30P twistlock input — straightforward to provision in any facility running standard 30A 208V branch circuits.
What sets the I10405 apart from a basic strip PDU is the hot-swap upgradeable architecture: when your monitoring requirements grow beyond the local display, you can retrofit an Interchangeable Monitoring Device (IMD) to convert it to a fully monitored rPDU without swapping the whole unit. That keeps initial hardware costs down while preserving a clear upgrade path as your operation scales. Explore the full Vertiv power infrastructure catalog for companion monitored and switched rPDU options.
Key Features
- 36 Mixed Outlets (20x IEC C13 / 4x IEC C19 / 12x NEMA 5-20R): The outlet mix handles the real-world diversity of a populated rack — C13 for 1U and 2U servers, C19 for high-draw UPS bypass or PDU-to-PDU whips, and 5-20R for KVM switches, crash carts, or local UPS units running 120V. Banked in groups of 5 (C13) and duplex pairs (5-20R), each bank maps cleanly to a breaker so you know exactly which devices trip if a circuit goes over.
- 30A / 5.7kW Input at 208V: Sized for a full high-density rack — 5.7kW at 208V is enough headroom for a typical dual-socket server row without leaving power stranded. Pair two of these on a 60A branch circuit (A+B feed) and you have a resilient dual-feed configuration standard in Tier II and Tier III facilities. Check rack PDU options for single-phase and three-phase alternatives when your load profile differs.
- Breaker-Level and Input-Level Monitoring: Three monitoring tiers are built in — aggregate unit totals (kWh, W, VA, PF), per-phase A/B breakdowns, and per-circuit breaker amperage. Power measurements on the unit and phase levels comply with ANSI C12.1 and IEC 62053-21 at 1% accuracy; breaker current is independently tested at 2% accuracy. That precision matters when you're capacity planning: you're not estimating, you're metering.
- Local High-Visibility Scrolling LED Display: Instant current readout at the unit without needing a laptop, an app, or network access. Useful during initial rack deployment when DHCP isn't live yet, or during troubleshooting when you can't reach the management plane. The display rotates through metrics so you're not hunting through menus.
- Dual 20A Double-Pole Magnetic Breakers: Magnetic breakers trip faster and more consistently than thermal alternatives under short-circuit conditions, and they reset cleanly without the cool-down period thermal breakers need. Each breaker carries half the load — 10x C13 outlets and 2x C19 outlets per breaker — so a single circuit event doesn't take the whole rack offline.
- Hot-Swap IMD Upgrade Path: The Upgradeable platform means you can add network-accessible monitoring later — IP address, SNMP, alerting, remote outlet switching (with the right IMD) — without pulling the PDU from the rack. For facilities in a phased buildout, this avoids the cost of buying fully monitored units on day one where they aren't yet needed.
- NEMA L14-30P Twistlock Input with 10ft / 3m Cord: The L14-30P plug locks positively into the receptacle — no accidental disconnects from cable tension or vibration. The 10ft cord gives enough reach from the floor PDU panel to the top of a standard 42U rack with the power entry at the bottom front of the unit.
- TAA and Buy American Act COTS Compliant: Manufactured in the USA, listed under UL and c-UL 62368-1, RoHS compliant, and FCC Part 15 Class A certified. TAA compliance means this unit is cleared for federal agency and government contractor deployments subject to the Trade Agreements Act. See data center power distribution for other TAA-compliant PDU configurations.
- Heavy Steel Powder-Coat Chassis — 70in Vertical: The 70in x 2in x 2in all-steel body mounts vertically in 0U space along the rack rail, leaving all rack units free for active equipment. Toolless mounting hardware accommodates 61.25in and 64.75in center-to-center rail spacing, covering the two most common rack configurations without adapters.
- 5-Year Limited Warranty: Vertiv backs this unit with a 5-year limited warranty — longer than the typical 1-3 year coverage on commodity PDUs, and meaningful for infrastructure you'll expect to run continuously for a full hardware refresh cycle. Every unit is 100% factory-tested before shipment.
Integration and Compatibility
The I10405 serves as the metered entry point in the Vertiv PowerIT rPDU ecosystem. It operates on single-phase 100-120V or 200-240V at 50/60Hz, making it compatible with standard North American data center branch circuits. The dual-phase (A and B) monitoring maps directly to dual-bus UPS output configurations common in enterprise UPS systems. For facilities using a data center infrastructure management (DCIM) platform, the IMD upgrade path provides the SNMP/network interface needed to feed real-time power data into capacity management tools. Pair with a compatible uninterruptible power supply on each feed leg for full dual-input fault tolerance. The maximum operating temperature of 60°C / 140°F means this unit handles even poorly cooled secondary spaces — edge deployments, IDF closets, or facilities running elevated rack inlet temperatures during summer peaks.
Frequently Asked Questions
Q: Can the I10405 be upgraded to a monitored rPDU later without replacing the unit?
A: Yes. The I10405 uses Vertiv's hot-swap Upgradeable architecture, which accepts an Interchangeable Monitoring Device (IMD) that converts it to a monitored rPDU with network access. The base metered unit provides local LED display and breaker-level monitoring; the IMD adds remote IP-based visibility and alerting.
Q: What plug does the I10405 use, and what branch circuit does it require?
A: The I10405 ships with a NEMA L14-30P twistlock plug on a 10ft/3m, 10/4 AWG power cord. It requires a 30A, 120/208V branch circuit. In dual-feed deployments, two units are typically connected to separate 30A legs of a 60A branch circuit panel feed.
Q: Is the I10405 TAA compliant for federal or government use?
A: Yes. The I10405 is manufactured in the USA and is listed as TAA Compliant and Buy American Act COTS Compliant, making it eligible for federal agency procurement and government contractor deployments subject to Trade Agreements Act requirements.
Q: What is the warranty on the I10405?
A: Vertiv provides a 5-year limited warranty on the I10405. Every unit is 100% factory tested before shipment.
Q: What is the accuracy of the power monitoring on the I10405?
A: Unit-level and phase-level power measurements (kWh, W, VA, PF, V, A) comply with ANSI C12.1 and IEC 62053-21 at 1% accuracy class. Breaker/circuit-level current measurements are independently tested and verified at 2% accuracy.
Q: How does the I10405 mount in a rack, and does it take up rack unit space?
A: The I10405 mounts vertically in 0U space along the interior rail of the rack, so it occupies no rack units. Toolless mounting hardware supports 61.25in and 64.75in center-to-center rail spacing. The chassis dimensions are 70in x 2in x 2in.
The I10405 is one of those units I recommend when a customer wants visibility into circuit-level loading today but doesn't want to commit to full remote monitoring pricing on every rack — the hot-swap IMD architecture means you're not painted into a corner. The 5.7kW/30A rating at 208V covers a realistic high-density compute rack, and the 36-outlet count (including 4x C19) handles the heaviest draws without adapter chains.
Technical Highlights:
- Three-Tier Monitoring (1% accuracy at unit/phase, 2% at breaker): ANSI C12.1 / IEC 62053-21 compliance on the aggregate and phase measurements means these aren't estimated readings — they're metered values you can use for chargeback billing or capacity planning with real confidence intervals.
- Dual 20A Magnetic Breakers: Magnetic trip vs. thermal means no waiting for the breaker to cool before a reset during an event. Each breaker independently protects half the C13 bank (10 outlets) and half the C19 bank (2 outlets), so a single overload condition is isolated to one circuit, not the full rack.
- TAA + Buy American Act COTS Compliant, Made in USA: For anyone deploying into federal facilities or DoD-adjacent environments, this clears the procurement gate without a waiver. Not all PDUs at this price point carry both TAA and BAA COTS status — it matters on government bids.
Deployment Considerations:
- The L14-30P twistlock is the right call for vibration-prone or high-traffic data hall environments, but confirm your branch circuit panel has L14-30R receptacles before ordering — a handful of older facilities still run L6-30R or straight-blade 30A configurations that need a PDU change or a panel adapter.
- The power entry is bottom-front: plan your cable management accordingly in floor-mount or open-frame rack configurations where the PDU sits flush to the rear rail — a rear-entry model may route cleaner depending on your cabinet layout.
This unit fits best in co-location cage deployments and enterprise server rooms where a facilities team needs circuit-level current data for capacity reporting but isn't yet running a DCIM platform that would justify a full remote monitoring card on every vertical PDU.
