Panduit CJ688TGOR-C Concise Descriptor

Overview

The Panduit CJ688TGOR-C is a Category 6 UTP (Unshielded Twisted Pair) keystone jack designed for high-performance network installations. It provides a robust termination point for 8-wire, 4-pair copper cabling, ensuring reliable data transmission up to Gigabit Ethernet speeds. This jack is ideal for structured cabling systems in commercial buildings, data centers, and enterprise environments where network integrity is critical. The TG style termination simplifies field installations, reducing potential errors and ensuring a secure connection for the CJ688TGOR-C.

Compatibility

This keystone jack is compatible with standard keystone wall plates, patch panels, and surface mount boxes designed to accept standard single-width keystone modules. It is engineered to meet or exceed Category 6 performance standards, ensuring compatibility with 1000BASE-T (Gigabit Ethernet) networks. It is suitable for use with 23-24 AWG solid conductor unshielded twisted pair copper cables.

Installation Notes

The CJ688TGOR-C features a TG style termination, requiring a standard punch-down tool (e.g., Panduit CT-AP, CT-PRO) for wire termination. Ensure wires are punched down firmly to establish proper electrical contact and strain relief. The jack is color-coded for T568A/B wiring schemes, facilitating correct installation. A minimum bend radius of 4x cable diameter should be maintained post-termination to prevent signal degradation.
