Panduit MINI-COM CM CAT 6 UTP ORNG PK 1 - CC688OR

Panduit CC688OR Concise Descriptor

Overview

The Panduit CC688OR is a Category 6 UTP (Unshielded Twisted Pair) MINI-COM connector designed for terminating network cables within patch panels or surface mount boxes. Its orange color provides clear visual identification for network segments, crucial in complex structured cabling deployments where cable management and segregation are paramount. This connector ensures reliable data transmission for 1000BASE-T Ethernet networks.

Compatibility

This connector is designed for use with Panduit's MINI-COM system, compatible with all Panduit faceplates, surface mount boxes, and patch panels that accept MINI-COM modules. It supports standard Category 6 UTP cabling infrastructure, suitable for use with most network switches and routers supporting Gigabit Ethernet (1000BASE-T) and lower speeds.

Installation Notes

Termination requires a standard punch-down tool (e.g., Panduit CT-300 or equivalent) to seat the conductors into the IDC (Insulation Displacement Connector) terminals. Ensure proper wire pairing according to T568A or T568B standards. A minimum bend radius of 4 times the cable diameter should be maintained post-termination to prevent signal degradation.

What's in the Box

• 1x Panduit CC688OR MINI-COM CM CAT 6 UTP ORNG PK 1
