Panduit CJSUD6A UP Down Jack Module

Overview

The Panduit Mini-Com® Cat 6A Shielded RJ45 Up/Down 45° Angled TG Jack Module (CJSUD6X88TGWHY) is engineered to terminate shielded 4-pair, 22-26 AWG twisted pair cable. Its angled design significantly improves cable routing in confined spaces, preventing sharp bends and strain on the cable jacket. This module is 100% factory tested to exceed industry standard performance requirements for Category 6A, ensuring reliable data transmission for demanding network applications.

Compatibility

This jack module is compatible with Panduit's Mini-Com Modular Patch Panels and Faceplates, providing a seamless integration into existing Panduit structured cabling systems. It supports IEEE 802.3af, 802.3at, and 802.3bt Type 3 and Type 4 Power over Ethernet (PoE++) standards, ensuring sufficient power delivery for connected devices without compromising network performance.

Installation Notes

The TG style termination on this module eliminates the need for a specialized termination tool, simplifying installation. Each jack is individually serialized for traceability. It meets channel and component requirements of ANSI/TIA-568.2-D and ISO 11801 standards for Category 6A, and is UL 1863 and UL 2043 compliant.
