Panduit CJUD688TGWH Cat 6 Up/Down RJ45 Jack Module

Panduit CJUD688TGWH Mini-Com Cat 6 Up/Down RJ45 Jack Module

The Panduit CJUD688TGWH addresses a common pain point in high-density rack and wall-mount installations: insufficient cable bend radius behind jack panels. This Mini-Com Cat 6 UTP jack module features a 45° up/down angled port orientation that redirects patch cords and permanent links away from the mounting plane, reducing strain on copper pairs and preserving Category 6 channel performance in shallow boxes, tight rack rails, and back-to-back panel configurations. Designed for commercial security integrators terminating 22-26 AWG twisted pair to PoE cameras, access readers, and IP intercoms, the module ships in off-white to match standard faceplates and delivers factory-tested gigabit performance with tool-less TG termination.

Key Features

• 45° up/down angled port geometry improves cable routing in constrained spaces and reduces bend-radius violations behind shallow wall boxes
• Tool-less TG termination accepts 22-26 AWG solid or stranded conductors without a punchdown tool, cutting install time per drop
• 100% factory tested to exceed ANSI/TIA-568.2-D and ISO 11801 Cat 6 component specs; supports 1000BASE-T and 10GBASE-T over short runs
• Supports IEEE 802.3af/at (PoE/PoE+) and 802.3bt Type 3/Type 4 (PoE++) for high-power PTZ cameras and multi-radio access points
• Rated for 2,500 connection cycles under PoE load; UL 1863 and UL 2043 plenum rated for in-ceiling and air-handling installations
• Individual module serialization enables end-to-end traceability in large campus deployments and simplifies warranty claims
• Snap-fits into all Mini-Com modular patch panels, surface boxes, and faceplates without adapters or brackets

The angled port design solves a recurring problem in retrofit security projects: you've pulled Cat 6 to a camera location, mounted a surface box on a column or soffit, and discovered the 90° bend from the back of a standard jack to the patch cord exceeds the 4× cable diameter minimum bend radius specified in TIA-568. Forcing the cable risks kink-induced return loss and insertion loss spikes that drop link speed or cause intermittent PoE brownouts. The CJUD688TGWH's upward or downward 45° exit angle (installer selects orientation at the time of termination by rotating the module 180° in the panel) cuts the effective bend angle in half, letting you maintain code-compliant geometry even when the box depth is only 1.5 inches. This is equally valuable in network closets with back-to-back ladder rack and zero rear clearance: angle the ports toward the cable tray and eliminate the horizontal dog-leg that consumes 2-3 inches of space per jack.

TG termination uses captive wire guides and a sliding cover that seats and trims all eight conductors simultaneously. Strip the jacket to the printed guideline, untwist each pair only as far as the color-coded wire slots, press conductors into the guides, and snap the cap shut—the integrated blades cut flush and the contact fingers pierce insulation to establish gas-tight connections. No impact tool, no individual punchdowns, no loose cut-offs in the box. Each module ships pre-tested with serialized performance data; Panduit's test report confirms insertion loss, return loss, NEXT, and FEXT margins across the full 1-250 MHz spectrum, so you're not relying on field certification alone to prove Cat 6 compliance. The jack meets IEC 60603-7 durability for 2,500 mating cycles while delivering PoE++ (up to 60W per port for Type 3, 100W for Type 4), which future-proofs the link for next-generation 4K cameras and Wi-Fi 6E APs that draw peak power during boot or high-traffic periods.

The module is UL 2043 plenum rated and RoHS compliant, meeting NEC Article 800 requirements for cable and connectivity installed above suspended ceilings or in air-return plenums. It snaps into any Mini-Com opening—modular panels, Panduit faceplates, or third-party Mini-Com-compatible surface boxes—giving you consistent termination mechanics across an entire structured cabling system. Off-white housing blends with standard electric-box covers and keeps the aesthetic clean in lobbies, conference rooms, and customer-facing spaces. For integrators managing large-scale access control or IP surveillance deployments where every camera drop and card reader homerun terminates at an IDF patch panel, the CJUD688TGWH delivers code-compliant bend radius, tool-free speed, and verified gigabit performance in a single field-replaceable module.
