Panduit CJ588RDY MCM CAT5E UTP 8POS8WIRE UNIVERSAL RED LEADFRAME STYLE

Overview

The Panduit CJ588RDY is a CAT5E UTP 8-position, 8-wire universal connector designed for structured cabling installations. Its leadframe style simplifies termination, making it suitable for network infrastructure deployments where reliable Category 5e performance is required. The red color coding aids in identification within complex wiring systems, ensuring proper cable management and troubleshooting.

Compatibility

This connector is designed for use with Category 5e UTP (Unshielded Twisted Pair) cabling. It is compatible with standard 24 AWG solid or stranded copper conductors, commonly found in commercial and residential network installations. It integrates with standard patch panels and wall plates supporting 8-position, 8-wire (8P8W) modular jacks.

Installation Notes

Termination requires a standard punch-down tool or a specialized Panduit crimp tool for leadframe connectors. Ensure conductors are properly seated into the leadframe slots before final compression. For optimal performance and to meet Category 5e specifications, maintain a minimum of 1.3 cm (0.5 in) of untwisted pair length at the termination point.
