Vertiv MXT5110-DVI DVI Matrix KVM Transmitter
Overview
The Vertiv MXT5110-DVI is the transmitter half of the Avocent Matrix switching platform — a hardware endpoint that captures DVI-I video at up to 1920x1200 and extends it alongside USB 2.0 keyboard/mouse control across an IP network. If you're distributing workstation access across a broadcast facility, control room, or operations center where operators need to reach multiple sources without pixel compromise, this is the unit that sits at the source end of that architecture.
Where conventional KVM extenders lock you into point-to-point runs, the Matrix platform routes signals dynamically — the MXT5110-DVI encodes the source signal on the IP network so any authorized receiver in the fabric can connect to it. That shift from dedicated cable runs to switched IP paths is the core value proposition for multi-operator, multi-source environments.
Key Features
- 1920x1200 DVI-I Video Output: Single-link DVI-I covers the full range of 16:10 and 16:9 professional monitor resolutions including 1920x1200 and 1080p — meaningful for CAD workstations, medical imaging displays, or broadcast monitors where pixel-accurate reproduction matters. Not limited to consumer HDTV resolutions.
- IP-Based Signal Distribution: Video and USB data ride a standard RJ-45 network connection, which means you're routing through your existing switched infrastructure rather than pulling dedicated extender cables for every source-receiver pair. Distance becomes a function of your network topology, not a fixed extender spec.
- USB 2.0 with Class Control: The single USB Type-B port supports USB 2.0 Hub functionality with Class Control, letting you pass keyboard and mouse while selectively allowing or blocking other USB device classes (storage, audio, etc.). That per-class gating is operationally important in secure or compliance-driven environments where you don't want operators plugging in arbitrary USB peripherals at remote endpoints.
- 100–240V Universal Power Input: Accepts 50/60 Hz AC from 100V to 240V without a voltage selector switch — deploy across North American, European, or Asian facilities on the same SKU without transformer concerns.
- 0–45°C Operating Range: Rated for standard indoor IT environments. Comfortable for rack rooms, control consoles, and wiring closets that maintain climate control — not rated for extreme environments, so plan accordingly if the transmitter lives outside a conditioned space.
- Compact Form Factor (120.65 × 157.48 × 30.73 mm, 0.64 kg): At under 160mm deep and 31mm tall, the unit fits neatly behind a monitor stand, on a desktop, or in a shallow mounting shelf without requiring rack space at the source end. The sub-kilogram weight keeps cable strain off the DVI port in tabletop deployments.
- CE and FCC Certified: Regulatory clearance for both North American (FCC) and European (CE) markets, which matters when you're deploying into enterprise or government facilities that require documented compliance at each node.
Integration and Compatibility
The MXT5110-DVI (often searched as MXT5110 DVI) is purpose-built for the Avocent Matrix ecosystem under the Vertiv brand. It pairs with a compatible Matrix receiver and is managed through the Avocent Matrix switching fabric. The DVI-I connector accepts both digital DVI-D and analog DVI-A signals from the source, offering flexibility across mixed-generation workstation environments. USB Class Control configuration is handled at the switch/management layer, not on the transmitter itself — verify receiver and management software compatibility before specifying this unit in a new installation. The 2-year manufacturer warranty covers the hardware through the standard deployment and commissioning window.
Frequently Asked Questions
Q: What video resolution does the MXT5110-DVI support?
A: The MXT5110-DVI supports video resolutions up to 1920x1200 via its DVI-I connection — covering both widescreen 16:10 professional displays and standard 1080p monitors.
Q: Does the MXT5110-DVI work as a standalone KVM extender?
A: No. The MXT5110-DVI is a transmitter node designed for the Avocent Matrix switching platform. It requires a compatible Matrix receiver and the appropriate switching/management infrastructure to function — it is not a point-to-point standalone extender.
Q: What USB devices can be passed through the MXT5110-DVI?
A: The unit supports USB 2.0 with Class Control, meaning you can pass keyboard and mouse traffic while selectively enabling or blocking other USB device classes such as storage or audio. Class Control policy is set at the management layer, not on the transmitter itself.
Q: What is the operating temperature range for the MXT5110-DVI?
A: The MXT5110-DVI is rated for operation between 0°C and 45°C (32°F to 122°F). It is designed for standard climate-controlled indoor environments — not for uncontrolled or outdoor installations.
Q: What is the warranty on the MXT5110-DVI?
A: The MXT5110-DVI carries a 2-year manufacturer warranty.
Q: Does the MXT5110-DVI require a dedicated network or can it run on an existing LAN?
A: It uses a standard RJ-45 network interface, so it can run on an existing switched IP network. However, Matrix platform deployments typically benefit from a dedicated VLAN or segmented network to ensure latency and bandwidth predictability — consult the Avocent Matrix system design guide for specific network requirements.
The MXT5110-DVI sits at the source end of an Avocent Matrix fabric, and the spec that most integrators underestimate is the USB Class Control feature on that single Type-B port. In operations center deployments — broadcast, utilities, NOC — the ability to pass HID devices while hard-blocking USB storage at the transmitter level is often a compliance requirement, not a nice-to-have. That distinction is worth verifying early in the design phase.
Technical Highlights:
- 1920x1200 DVI-I: Full single-link DVI bandwidth covers the 1920x1200 resolution used by many 24-inch professional displays — not artificially capped at 1080p, which matters for operators running financial or CAD applications that use the extra vertical pixels.
- 0.64 kg / 120.65 × 157.48 × 30.73 mm: The transmitter is compact enough to tuck behind a workstation monitor arm or mount on a shallow shelf — keeps the source-side installation tidy without requiring rack space at every seat.
- 100–240V universal input: Single-SKU deployment across mixed-voltage facilities; no country-specific power accessories to track in a global rollout.
Deployment Considerations:
- The MXT5110-DVI has no standalone operating mode — it requires a Matrix receiver and management infrastructure on the same network fabric before it does anything. Budget for the full system, not just the transmitter count.
- Operating ceiling is 45°C — if the transmitter lives in an unventilated AV rack or equipment closet that runs hot, confirm ambient temperatures stay under that threshold or add cooling. Storage is rated to 70°C but operation is not.
This transmitter is the right fit for operations centers and broadcast control rooms where the source-side deployment needs to be physically minimal, USB device policy needs to be enforced at the hardware layer, and the signal distribution architecture is already committed to the Avocent Matrix platform.
