Vertiv AFPSPLITTER AFP Splitter for Matrix KVM
Overview
The Vertiv AFPSPLITTER is a signal-splitting accessory designed for use with Vertiv's AFP Matrix KVM systems, extending RS-232 connectivity across multiple remote KVM switch ports. If your matrix deployment requires serial control paths — for managed devices, out-of-band management, or legacy serial-controlled endpoints — this splitter addresses the distribution layer without requiring additional dedicated serial infrastructure. Each output port on the AFP0004 and AFP0008 remote KVM switch variants carries a single RS-232 connection, meaning the AFPSPLITTER slots directly into an existing Vertiv Vertiv KVM and matrix architecture rather than introducing a parallel wiring plant.
For integrators building out KVM switch environments where serial control of remote nodes is a hard requirement — data centers, broadcast facilities, industrial control rooms — the AFPSPLITTER handles the distribution function without forcing a rearchitecture of the primary KVM fabric.
Key Features
- RS-232 Output per Port: Each AFP0004 and AFP0008 remote KVM switch port provides one RS-232 connection through the AFPSPLITTER — serial control reaches individual endpoints without a separate serial concentrator, which reduces rack unit count and cabling complexity at the remote node.
- Matrix-Native Integration: Designed specifically for the Vertiv AFP Matrix platform, which means configuration and signal path are validated against the matrix's own timing and protocol handling. Third-party splitters in this role often introduce compatibility issues; a platform-matched component avoids that class of problem entirely.
- Dedicated Accessory Role: As a purpose-built splitter rather than a general-purpose RS-232 hub, the AFPSPLITTER keeps the serial path deterministic — important when the downstream devices rely on serial handshaking for managed switching or device authentication.
Integration & Compatibility
The AFPSPLITTER is designed to pair with the Vertiv AFP Matrix KVM line, specifically with AFP0004 and AFP0008 remote KVM switch units. Confirm your matrix model against Vertiv's AFP platform compatibility documentation before ordering — the AFP splitter architecture is platform-specific, and cross-platform use is not supported by available evidence. For broader server and KVM management planning, verify RS-232 device requirements at each remote endpoint against the port allocation the matrix supports.
Frequently Asked Questions
Q: What matrix platform is the AFPSPLITTER compatible with?
A: The AFPSPLITTER is designed for use with the Vertiv AFP Matrix KVM system, specifically with AFP0004 and AFP0008 remote KVM switch units. Compatibility with other Vertiv matrix lines is not confirmed by available evidence — verify against your specific matrix model before ordering.
Q: What type of serial port does the AFPSPLITTER provide?
A: Each output port on the AFP0004 and AFP0008 remote KVM switch units provides one RS-232 connection through the AFPSPLITTER.
Q: Is the AFPSPLITTER a standalone device or does it require an AFP Matrix system?
A: The AFPSPLITTER is an accessory component designed to work within a Vertiv AFP Matrix KVM deployment. It is not a standalone device and requires an AFP Matrix system to function.
Q: Does the AFPSPLITTER support any other serial standards beyond RS-232?
A: Based on available evidence, the AFPSPLITTER provides RS-232 connectivity. Support for RS-422, RS-485, or other serial standards is not confirmed — consult Vertiv's AFP platform documentation for full serial specifications.
The AFPSPLITTER's primary value in an AFP Matrix deployment is straightforward: it puts RS-232 on each remote KVM port without requiring a separate serial concentrator at the remote end. If you're managing serial-controlled devices — managed PDUs, OOB consoles, legacy serial-only equipment — through an AFP0004 or AFP0008 remote switch, the AFPSPLITTER handles that distribution in-path rather than as a bolt-on.
Technical Highlights:
- RS-232 per output port: Each AFP0004 and AFP0008 remote KVM switch port carries one RS-232 connection via the AFPSPLITTER — serial control is port-local, not shared across endpoints, which keeps device addressing clean in multi-node racks.
- Platform-matched design: Built specifically for the Vertiv AFP Matrix line; signal timing and protocol handling are validated against the AFP platform's own specs rather than generic RS-232 pass-through behavior.
- Accessory-class simplicity: No configuration, no firmware — the AFPSPLITTER is a passive distribution component, which means zero maintenance overhead once it's wired into the matrix.
Deployment Considerations:
- Confirm AFP Matrix model compatibility before ordering — the AFPSPLITTER is platform-specific to the AFP line; it is not a general-purpose RS-232 splitter and won't function correctly outside that architecture.
- Available evidence covers RS-232 only; if your remote devices require RS-422 or RS-485, verify serial standard support directly with Vertiv's AFP platform documentation before committing to this component.
The AFPSPLITTER is the right call for data center and industrial control room deployments running the Vertiv AFP Matrix where serial device control at each remote node is a hard requirement — not an afterthought addressed with a cable pile.
