Vertiv AFP0008 8-Port Active Front Panel Remote Control
Overview
The Vertiv AFP0008 is an 8-port active front panel designed for console switching environments where direct RS-232 serial control is required. At 10.4 inches wide and just 0.7 inches tall, the AFP0008 integrates cleanly into existing 1U rack form factors without consuming additional rack space — a practical choice for data centers, server rooms, and network operations centers where rail space is a persistent constraint. The AFP0008 pairs with Vertiv's KVM switch lineup to give operators front-panel access and control without requiring a dedicated KVM console in every rack bay.
If you're evaluating the 4-port variant, the Vertiv AFP0004 measures 6.5 inches wide and weighs 0.125 lbs — useful in smaller rack deployments where fewer server connections are needed. The AFP0008 scales up to 8 ports, making it the right unit for denser multi-server installations.
Key Features
- 8-Port Configuration: Supports up to 8 server or device connections from a single front panel — versus the 4-port AFP0004, this doubles the switching capacity without adding rack height, keeping your console access consolidated on a single panel.
- RS-232 Serial Output: The single RS-232 output port provides direct serial connectivity to your KVM infrastructure. RS-232 is a widely supported, low-latency protocol for out-of-band management — meaning you retain console access even when the primary network path is down, which is exactly when you need it most.
- Ultra-Low Profile (0.7" Height): At just 0.7 inches tall, the AFP0008 occupies minimal vertical rack space. In high-density deployments where every rack unit counts, a sub-1U front panel that handles 8 connections is a meaningful space saver versus mounting discrete per-server access panels.
- 10.4-Inch Width: Sized to span a standard 19-inch rack bay's accessible width. This form factor is designed for front-panel mounting scenarios where the panel must remain accessible without obstruction from adjacent equipment.
- Lightweight Construction (0.1875 lbs): At under 0.2 lbs, the AFP0008 adds negligible load to rack door or front-panel mounting points — relevant in mobile rack or field-deployed configurations where weight budgets matter.
- Compact Depth (1.3 inches): A 1.3-inch depth means the AFP0008 doesn't project far beyond the rack front rail, keeping clearance available for cable management and door closure in shallow rack enclosures.
Integration and Compatibility
The AFP0008 is designed for use within Vertiv's KVM and console management ecosystem. The RS-232 output interfaces with compatible Vertiv KVM switches and console servers. If you're building or expanding a KVM switching infrastructure, verify compatibility with your specific Vertiv KVM switch model before ordering — the AFP0008 is intended as a front-panel extension within the Vertiv product family, not a standalone switching device.
For environments running out-of-band management alongside KVM, the RS-232 interface aligns with standard serial console server deployments. Pair the AFP0008 with a compatible serial console server or Vertiv KVM unit to complete the access chain. When planning cable routing, account for the 1.3-inch panel depth and confirm that your rack's front-door clearance accommodates front-panel accessories at this profile.
Frequently Asked Questions
Q: What is the difference between the AFP0008 and the AFP0004?
A: The AFP0008 supports 8 ports and measures 10.4 inches wide, weighing 0.1875 lbs. The AFP0004 supports 4 ports, is 6.5 inches wide, and weighs 0.125 lbs. Both share the same 0.7-inch height and 1.3-inch depth and both use a single RS-232 output. Choose the AFP0008 for higher-density server consolidation; the AFP0004 for smaller deployments.
Q: What type of output does the AFP0008 use?
A: The AFP0008 provides one RS-232 serial output port. This is the connection from the front panel to your KVM switch or console management infrastructure.
Q: How much rack space does the AFP0008 require?
A: The AFP0008 is 0.7 inches tall, 10.4 inches wide, and 1.3 inches deep. It is designed for front-panel mounting within a standard 19-inch rack enclosure and does not consume a full 1U slot in the traditional sense — verify mounting compatibility with your specific rack model.
Q: What does the AFP0008 weigh?
A: The AFP0008 weighs 0.1875 lbs, making it suitable for front-panel or door-mount applications where load capacity is limited.
Q: Is the AFP0008 a standalone KVM switch?
A: No. The AFP0008 is an active front panel remote control — it is designed to work in conjunction with a compatible Vertiv KVM switch, not as a standalone switching device. Confirm compatibility with your existing Vertiv KVM infrastructure before purchase.
The AFP0008 is one of those components that doesn't get much attention until someone needs front-panel access to 8 servers and realizes they never planned for it. At 0.7 inches tall and 10.4 inches wide, this panel slots into the front of a rack without claiming a full unit of vertical space — and that single RS-232 output is the link that ties it back into your Vertiv KVM infrastructure for out-of-band console control.
Technical Highlights:
- 8-Port Capacity: Doubles the AFP0004's connection count in the same 0.7-inch height profile — relevant when you're consolidating console access across a dense server row and don't want a separate panel per bay.
- RS-232 Serial Interface: One output port to the KVM switch. RS-232 is protocol-stable and well-supported across Vertiv's console management line — no driver dependencies, no network path required for the control signal itself.
- 0.1875 lb Weight: Light enough for front-door or swing-arm mounting without stressing rack door hinges — a detail that matters in mobile or temporary deployment racks where door load specs are tight.
Deployment Considerations:
- The AFP0008 is a front-panel extension, not a standalone switch — you need a compatible Vertiv KVM switch in the chain for it to function. Confirm model compatibility with your existing Vertiv unit before purchase.
- At 1.3 inches deep, verify that your rack's front door or bezel clears this depth when closed — shallow rack enclosures with tight door tolerances can conflict with front-panel accessories at this profile.
The AFP0008 is best suited for NOC or data center racks running Vertiv KVM infrastructure where 8-port front-panel access consolidation is the goal and rack space is at a premium.
