Lifesafety Power FPO150-B1002D8PM8NLCE6M/P8-A 150W Power Supply
Overview
The FPO150-B1002D8PM8NLCE6M/P8-A is a 150W supervised power supply designed for access control, intrusion, and low-voltage security system integration. It delivers either 12A at 12V or 6A at 24V from the primary output — sufficient to drive multiple card readers, door strikes, and auxiliary equipment without undersizing the primary bus. The unit includes 8 independent DC auxiliary outputs, each fused at 3A and selectable on a per-output basis for Bus1 or Bus2 assignment. Class 2 power-limited operation (2.5A per auxiliary) meets life-safety code requirements for installations where power supervision and fault isolation are non-negotiable.
Compatibility
The FPO150-B1002D8PM8NLCE6M/P8-A integrates into Lifesafety Power system architectures supporting Bus1/Bus2 topology. The selectable auxiliary outputs allow independent routing of low-current loads (keypads, indicator lights, magnetic locks rated under 2.5A per channel) without sharing fuses or forcing daisy-chain wiring. Field-verifiable via part number: confirm your panel's bus architecture documentation before ordering.
Installation Notes
The E6 enclosure form factor measures 30H × 23W × 6.5D inches — sized for wall-mount in utility closets or equipment racks. Each of the 8 auxiliary outputs is individually fused; a tripped 3A fuse isolates only that circuit, not the primary supply or adjacent auxiliaries. Verify incoming AC feed matches the unit's voltage rating before connection. The supervised topology requires appropriate telemetry wiring to your control panel; consult the system integrator or panel documentation for bus termination and voltage monitoring probe placement.
What's in the Box
- 1x FPO150-B1002D8PM8NLCE6M/P8-A power supply unit (E6 enclosure)
- 8x Class 2 power-limited auxiliary output modules (fused)
- Mounting hardware for wall installation
