Lenovo 7ZT7A00534 Thinksystem Intel I350-T2 PCIE 1GB 2-PORT RJ45 Ethernet Adapter

Lenovo 7ZT7A00534 ThinSystem Intel I350-T2 PCIe 1Gb 2-Port RJ45 Ethernet Adapter

Overview

The Lenovo 7ZT7A00534 is a dual-port Gigabit Ethernet network adapter designed for integration into servers. It provides reliable, high-speed wired connectivity for data transfer and network communication, supporting up to 1000 Mbit/s per port. This adapter is ideal for environments requiring stable network performance, such as data centers or enterprise server racks, and features Wake-on-LAN capabilities for remote management.

Compatibility

This adapter is compatible with server systems utilizing a PCI Express (PCIe) host interface. It is intended for installation within compatible Lenovo ThinkSystem servers and other server platforms that support standard PCIe network interface cards. Specific server model compatibility should be verified against Lenovo's server technical specifications for PCIe card integration.

Installation Notes

The Lenovo 7ZT7A00534 requires an available PCI Express slot within the host server. Operating temperature ranges from 0 to 55 °C, with storage temperatures between -20 and 65 °C. Relative humidity for operation is 10–90% non-condensing, and 5–80% for storage. The adapter supports Jumbo frames up to 9500 bytes, which can improve network efficiency for large data transfers by reducing packet overhead. VLAN tagging (IEEE 802.1Q) is supported for network segmentation.
