Lenovo 4XH7A96831 SR630 V4 4x2.5" SAS/SATA Backplane Kit

Overview

The Lenovo 4XH7A96831 is a SAS/SATA backplane kit that adds a 4x 2.5" drive bay configuration to the ThinkSystem SR630 V4 server platform. If you're expanding storage density in a 1U footprint without swapping chassis, this kit is the direct path — it installs into the SR630 V4's modular drive bay architecture and connects via the server's native SAS/SATA controller pathways, preserving your existing HBA or RAID configuration. Dual-interface support (SAS and SATA) means you can mix drive types across bays — useful when pairing high-endurance SAS drives for write-heavy workloads with SATA capacity drives for tiered or archival storage in the same tray.

Compatibility

Designed specifically for the Lenovo ThinkSystem SR630 V4 (Machine Types 7DG9, 7DG8, 7DLM). The SR630 V4 is a 1U rack server supporting Intel Xeon 6 P-series and E-series processors. This backplane kit is not interchangeable with the SR630 V3 or earlier SR630 variants — bay architecture and connector pinouts differ between generations. If you're running a server storage expansion project across a mixed SR630 V3/V4 fleet, verify chassis generation before ordering. The SR630 V4 supports both the 10x2.5" (feature code C1XE) and E3.S (C1XG) chassis configurations; confirm your chassis variant accepts the 4x2.5" backplane layout before provisioning. Compatible with the SR630 V4's hot-swap drive subsystem — drives, PSUs, and fans all remain field-serviceable after installation.

Installation Notes

The kit ships at 10 lbs — account for this when planning rack density and rail load ratings in dense 1U configurations. SAS/SATA dual-interface means the backplane will connect to either a SAS HBA or the platform's integrated SATA controller, but verify your specific RAID adapter supports the bay count you're targeting before installation. No optical or tape drive bays are present in the SR630 V4 chassis, so all internal storage routes through backplane connections like this kit.

Expert Analysis
Specifications
Weight: 10.00 lb
Country Origin: MX
Interface: SAS, SATA
Country Of Origin: MX
Unspsc Code: 43211600
Feature: SR630 V3
Networking: 1x OCP slot with PCIe Gen 5 x16 interface (rear or front of server) Additional PCIe adapters supported
Power: 750W, 1100W, 1800W AC Platinum/Titanium Hot Plug PSUs CFFv4 form factor power supplies 1300W -48VDC power supplies 240V HVDC support for PRC customers
Components: Specification
Form Factor: 1U rack
Chipset: None. Integrated into the processor
Memory Maximum: Up to 8TB by using 32x 256GB 3DS RDIMMs
Memory Protection: ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs), and memory mirroring.
Optical Drive Bays: No internal optical drive.
Tape Drive Bays: No internal backup drive.
Gpu Support: Support for up to 3x single-wide GPUs
Hot-Swap Parts: Drives, power supplies, and fans.
Operating Systems Supported: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server. See the Operating system support section for specifics.
Machine Type/Model General Purpose: Machine Type/Model for AI and HPC
7Dg9Cto1Ww: 7DG9CTOLWW
7Dg8Cto1Ww: 7DG8CTOLWW
7Dlmcto1Ww: 7DLMCTOLWW
Machine Type/Model: Description
7Dg9Cto2Ww: ThinkSystem SR630 V4 Workstation - 3 year Warranty
7Dg8Cto2Ww: ThinkSystem SR630 V4 Workstation - 1 year Warranty
Feature Code: Description
C1Xe: ThinkSystem 1U V4 10x2.5" Chassis
C1Xg: ThinkSystem 1U V4 E3.S Chassis
