Lenovo 4X97A59803 SR860 V2 16/32i RAID Cable Accessories Kit

Overview

The Lenovo 4X97A59803 is a RAID cable accessories kit designed for the ThinkSystem SR860 V2 4U rack server, specifically supporting storage controller configurations that use 16i and 32i RAID or HBA adapters. If you are expanding or reconfiguring internal storage paths on an SR860 V2 — particularly when adding backplane tiers or transitioning between starting and target controller topologies — this kit provides the internal cabling necessary to complete the installation without sourcing cables individually.

Compatibility

This kit is designed for the Lenovo ThinkSystem SR860 V2 server, covering machine types 7Z59 (1-year warranty builds), 7Z60 (3-year warranty builds), and 7D42 (SAP HANA configurations with 3-year warranty). Within the SR860 V2 platform, the 16i/32i cable path supports configurations such as a 1x RAID/HBA 16i starting config scaling to 3x RAID/HBA 16i (16+16+16), or an OB SATA (8) starting config routing through a RAID 32i plus additional 16i adapter. It is intended for use with RAID and HBA controllers in that adapter family — confirm your exact backplane and controller configuration against Lenovo's SR860 V2 configuration guide before ordering, as cable routing requirements vary by starting and target storage topology. Not compatible with NVMe-only backplane paths or the Switch/Retimer NVMe cable kit (4X97A59822) or M.2 cable kit (4X97A59828).

Installation Notes

Internal installation requires the server chassis to be powered down and the SR860 V2 to be accessible on a service rail. Cable routing follows Lenovo's prescribed backplane-to-controller paths for the 16i/32i adapter topology — consult the SR860 V2 server accessories installation guide for connector assignments and cable management clip locations. The SR860 V2 chassis is 447 mm wide, 175 mm tall, and 807 mm deep (17.6 × 6.9 × 31.8 in.), so verify rack depth clearance before servicing. This kit ships at approximately 60 lb combined package weight — plan accordingly for bench staging.

Expert Analysis
Specifications
Weight: 60.00 lb
Unspsc Code: 43211600
Components: Specification
Machine Types: 7Z59 - 1-year warranty 7Z60 - 3-year warranty 7D42 - SAP HANA configurations with 3-year warranty
Form Factor: 4U rack.
Chipset: Intel C621A "Lewisburg" chipset, part of the platform codenamed "Cedar Island" (CDS)
Persistent Memory: To avoid triggering throttle, it is advised that the ambient temperature is kept 27°C or lower when persistent memory modules are installed.
Memory Protection: ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs), memory mirroring.
Maximum Internal Storage: 1474.56TB using 48x 30.72TB 2.5-inch SAS/SATA SSDs 368.64TB using 24x 15.36TB 2.5-inch NVMe SSDs 115.2TB using 48x 2.4TB 2.5-inch HDDs Mix of NVMe/SSDs/HDDs supported.
Optical Drive Bays: No internal optical drive.
Tape Drive Bays: No internal backup drive.
Gpu Support: Supports up to 8x single-wide GPUs or up to 4x double-wide GPUs
Video: G200 graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller. Maximum resolution is 1920x1200 32bpp at 60Hz.
Hot-Swap Parts: Drives, fans and power supplies.
Operating Systems Supported: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating system support section for specifics.
Dimensions: Width: 447 mm (17.6 in.), height: 175 mm (6.9 in.), depth: 807 mm (31.8 in.). See Physical and electrical specifications for details.
Machine Type/Model General Purpose: Machine Type/Model for AI and HPC
7Z60Cto1Ww: 7Z60CTOLWW
7Z60Ctoaww: 7Z60CTOHWW
7Z59Cto1Ww: 7Z59CTOLWW
7Y38Cto1Ww: 7Y38CTOLWW
7D42Cto1Ww: 7D42CTOLWW
Model: Description
7Z60A00Jap: 2x Gold 5318H 18C 150W 2.5GHz
7Z60A00Hap: 2x Gold 5320H 20C 150W 2.4GHz
7Z60A00Gap: 2x Gold 6330H 24C 150W 2.0GHz
7Z60A00Kap: 2x Platinum 8354H 18C 205W 3.1GHz
7Z60A00Nea: 4x Gold 5318H 18C 150W 2.5GHz
7Z60A00Mea: 4x Gold 6330H 24C 150W 2.0GHz
7Z60A00Lea: 4x Platinum 8360H 24C 225W 3.0GHz
4B27A09311: BAVY
