Lenovo 4X97A59795 SR630 V2 10 Anybay BP NVME Cable KIT

Lenovo 4X97A59795 SR630 V2 10-Bay Anybay NVMe Cable Kit

Overview

The Lenovo 4X97A59795 is the OEM NVMe cable kit designed specifically for the ThinkSystem SR630 V2 server equipped with a 10-bay Anybay backplane. If you are wiring NVMe drives directly to the system board or an NVMe HBA in an SR630 V2 chassis, this kit delivers the correct cable routing and connector geometry to support full NVMe signaling — without adapter cards or makeshift cabling. The 4X97A59795 eliminates guesswork on connector type, cable length, and routing path, which matters on a 1U chassis where clearance is tight and improper cable runs restrict airflow and increase thermal risk.

Compatibility

This cable kit is matched to the Lenovo ThinkSystem SR630 V2 (7Z71, 7Z72 chassis variants) configured with the 10-bay 2.5-inch Anybay backplane. The Anybay backplane supports both SAS/SATA and NVMe drive populations in the same bay array; this specific cable kit enables the NVMe signal path for that backplane configuration. It is not interchangeable with SR630 V1 cable kits, SR650, or SR650 V2 assemblies — backplane connector placement and cable routing differ across generations. Verify your SR630 V2 backplane part number before ordering to confirm the 10-bay Anybay variant is installed.

Installation Notes

Route NVMe cables after all other internal cabling is complete — on a 1U platform like the SR630 V2, cable order affects whether the top cover seats correctly. Follow Lenovo's maintenance manual cable routing diagrams for the 10-bay Anybay configuration; incorrect routing can block the fan tray or prevent lid closure. This is a server internal cable assembly intended for trained data center technicians familiar with Lenovo ThinkSystem service procedures.
