Panduit CMDSORLCZBL LC Duplex Adapter Module

Panduit CMDSORLCZBL Mini-Com LC Duplex Adapter Module

The Panduit CMDSORLCZBL is a small form factor LC duplex adapter module engineered for high-density fiber termination in structured cabling systems. This Mini-Com® module couples two LC duplex connectors in a single module footprint, delivering space-efficient multimode connectivity for 10/40/100 Gigabit Ethernet links. The orange adapter body follows TIA-598 color coding for OM3/OM4 multimode fiber, while zirconia ceramic split sleeves ensure low insertion loss and repeatable performance across thousands of mate cycles. Integrated panel retention clips lock the module into Mini-Com faceplates, patch panels, and surface-mount boxes without tools, streamlining moves-adds-changes in enterprise networks and data centers.

Key Features

• LC duplex adapter fits two LC duplex connectors in one Mini-Com module space
• Orange adapter body identifies OM3/OM4 multimode fiber per TIA-598 color standard
• Zirconia ceramic split sleeves deliver low insertion loss and high durability
• Integrated panel retention clips secure module to faceplates and panels without screws
• Black module housing blends into professional AV and IT rack environments
• TIA/EIA-605 FOCIS-10 compliant for standards-based interoperability
• Non-keyed design accepts standard LC duplex connectors from any vendor
• Exceeds TIA/EIA-568-B.3 performance requirements for commercial cabling

Mini-Com adapters are the workhorse termination platform for Panduit's modular copper and fiber infrastructure. The CMDSORLCZBL addresses the high port density demands of 10/40/100GbE spine-leaf architectures, storage area networks, and fiber-to-the-desk rollouts where rack space is at a premium. The small form factor LC interface delivers twice the port density of SC adapters in the same panel real estate, while the duplex configuration keeps transmit and receive fibers paired and polarity-aligned. Zirconia split sleeves offer superior mechanical precision compared to phosphor bronze or polymer sleeves—critical when insertion loss budgets are tight in 40GBASE-SR4 or 100GBASE-SR10 links. The orange adapter body provides instant visual confirmation of multimode fiber, reducing the risk of accidentally cross-connecting singlemode and multimode fibers during MAC work. Integrated retention clips snap into any Mini-Com opening with an audible click, eliminating the fumble time and dropped screws common with threaded adapters.

The CMDSORLCZBL is designed for horizontal and backbone cabling in commercial buildings, data centers, healthcare campuses, and higher-education networks. Use it to terminate OM3 or OM4 multimode fiber in telecom rooms, equipment distribution areas, and zone enclosures where space constraints favor high-density panels. The module fits Panduit's Mini-Com faceplates (single-gang to six-gang), high-density patch panels, and surface-mount boxes, giving you a consistent termination platform across copper and fiber media. Pair it with Panduit's LC duplex patch cords and cassettes for a fully validated end-to-end system. The non-keyed design accepts LC connectors from any manufacturer, so you can mix vendor patch cords or integrate legacy fiber runs without compatibility issues. Black module housing is preferred in AV control rooms, server racks, and broadcast facilities where color-coded faceplates might clash with equipment aesthetics or client branding.

The CMDSORLCZBL ships as a single module (carton quantity 10) and is RoHS compliant for deployment in EU and California-regulated environments. It exceeds TIA/EIA-568-B.3 performance specifications, ensuring compatibility with warranty requirements for structured cabling systems from Panduit and third-party integrators. Zirconia split sleeves are rated for 500+ insertion cycles, matching the service life of enterprise patch panels and reducing the total cost of ownership in high-churn environments. The FOCIS-10 adapter interface is backward-compatible with legacy LC connectors, protecting your investment if you upgrade from OM3 to OM4 fiber or migrate to BiDi transceivers in the future. For integrators running mixed OM3/OM4 backbones in 10G-to-100G migrations, the orange color code and duplex retention clips make this adapter the low-risk, high-density choice for TIA-compliant fiber termination.
