ACTi KIT Wallmount Poe+ NO RFID Aa-rd BLK - 185-00109

ACTi 185-00109 PoE+ Wall Mount Kit

Overview

The ACTi 185-00109 is a wall-mount installation kit designed for PoE+ surveillance cameras. It provides the mechanical and electrical infrastructure needed to deploy IP cameras on building exteriors, entryways, or interior walls where direct surface mounting is required. The kit includes wall-mounting hardware and supports PoE+ (802.3at) power delivery, eliminating the need for separate power supplies in most standard deployments.

Compatibility

This mount is compatible with ACTi surveillance camera models that support PoE+ power input and standard wall-mount configurations. Verify camera mounting interface specifications against your target model before ordering—not all ACTi cameras use the same mounting footprint. If integrating into an existing ACTi system, confirm the specific camera series (e.g., ACTi dome, bullet, or box form factors) and mounting bracket compatibility with the 185-00109 hardware.

Installation Notes

Mount directly to concrete, brick, or wood framing using the included fasteners. PoE+ power draw depends on the connected camera—most ACTi models draw under 25W, well within 802.3at limits (30W). Run a single Ethernet cable to the camera; PoE+ injectors or powered switch ports deliver both power and video over one Cat5e or Cat6 line. No separate 12V supply required. Position the camera to avoid direct sun glare on the lens and ensure the Ethernet path has protection from UV exposure and mechanical stress. For exterior installations, verify wall material load capacity exceeds the combined weight of the mount, camera, and lens.

What's in the Box

• Wall-mount bracket with standard camera interface
• Fasteners for concrete, brick, or wood stud mounting
• Installation template and basic hardware
