Transition Networks M/E-ISW-FX-02(SC) Industrial Mini Converter
Overview
The Transition Networks M/E-ISW-FX-02(SC) is an industrial-grade media converter designed to bridge the gap between copper Ethernet and fiber optic networks in demanding environments. It converts a 10/100BaseTX copper Ethernet signal to a 100BaseFX multimode fiber signal, enabling network extension up to 2 kilometers. This unit is essential for extending network reach beyond the limitations of copper cabling, making it suitable for factory floors, utility substations, or transportation hubs where robust connectivity is critical.
Compatibility
This converter is designed to interface with standard 10/100BaseTX Ethernet ports found on industrial switches, IP cameras, and other network devices. The 100BaseFX output utilizes an SC connector for multimode fiber, compatible with standard multimode fiber optic patch cords and infrastructure. It functions as a transparent bridge, meaning it does not require specific software or firmware compatibility with the connected network equipment, as long as the equipment adheres to Ethernet standards.
Installation Notes
The M/E-ISW-FX-02(SC) is designed for DIN-rail mounting, a common standard in industrial control cabinets. Ensure the fiber optic connections are clean before mating the SC connectors to prevent signal degradation. The unit operates within a wide temperature range, suitable for harsh industrial settings. Power is supplied via a terminal block; verify the input voltage requirements match your power source before installation.
What's in the Box
- 1x M/E-ISW-FX-02(SC) Industrial Mini Converter
- 1x DIN-rail mounting clip
- 1x Terminal block power connector
