i-PRO WV-S8574L B2 33MP 4x4K Outdoor Dome Camera

i-PRO WV-S8574L B2 33MP 4x4K Outdoor Multi-Sensor Dome Camera

The i-PRO WV-S8574L B2 is a professional-grade 4x4K (33MP) outdoor multi-sensor network camera engineered for enterprises and security integrators requiring comprehensive 360° coverage from a single device. Combining four synchronized 4K sensor arrays, advanced AI analytics, and vandal-resistant construction, this camera delivers exceptional wide-area monitoring efficiency while reducing infrastructure complexity and deployment costs.

Key Features

• 33MP 4x4K Multi-Sensor Array: Four 4K sensors simultaneously capture 3840×2160 resolution at 15fps, totaling 33 megapixels for detailed forensic-quality imagery across entire perimeter surveillance zones
• 360° Omnidirectional Coverage: Eliminates blind spots with single IP address and one LAN cable connection, replacing multiple traditional cameras with unified deployment architecture
• Built-in AI Engine: Runs up to four concurrent AI applications simultaneously with intelligent object classification including people and vehicle detection, significantly reducing false alarms
• IK10 Vandal Resistance: Exceeds IEC 62262 impact rating with aluminum die-cast construction and corrosion-resistant stainless steel fasteners for harsh outdoor environments
• 120dB Super Dynamic Range: Handles extreme lighting transitions from bright sunlight to deep shadows without image degradation
• 40m IR Night Vision: Built-in infrared LEDs enable 24/7 operation with clear visibility in complete darkness
• FIPS 140-2 Level 3 Security: EdgeLock SE050F hardware security module protects against advanced cyber threats with signed firmware and HTTPS encryption
• PoE+ Powered: Single power delivery via Ethernet with optional Wi-Fi and USB connectivity for flexible integration

Technical Specifications

• Resolution: 33MP (4x4K multi-sensor)
• Field of View: 360°
• IR Distance: 40m with built-in LEDs
• IP Rating: IP67, NEMA 4X
• Vandal Rating: IK10
• Video Compression: H.265, H.264, MJPEG
• Operating Temperature: -40°C to +60°C
• Power Consumption: 25.4W via PoE+ (Class 4)
• Connectivity: Ethernet, Wi-Fi, USB
• Audio Support: Yes
• Analytics: Facial recognition, object classification
• Storage: microSD card support
• Standards: ONVIF compliant

Applications

• Perimeter security for airports, ports, and critical infrastructure
• Enterprise campus surveillance and parking facility monitoring
• Municipal traffic management and public space security
• Large-scale retail and warehouse operations
• High-security facilities requiring forensic-quality imagery and AI-driven threat detection

James Everett

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The WV-S8574L B2 represents a significant efficiency gain for security architects managing large outdoor deployments. The four-sensor architecture consolidates what traditionally requires 2–3 separate cameras into a single compact dome, reducing cable runs, power delivery infrastructure, and network bandwidth consumption. The 120dB WDR combined with 40m IR capability ensures consistent image quality across variable outdoor conditions without color shift or washout common in lesser designs.

The integrated AI engine distinguishes this platform from basic multi-sensor competitors. Simultaneous facial recognition, people counting, and vehicle classification enable real-time threat response without external GPU processing. FIPS 140-2 Level 3 certification with EdgeLock SE050F hardware crypto meets stringent requirements for government and financial sector deployments where firmware tampering or man-in-the-middle attacks present unacceptable risk.

PoE+ power at 25.4W consumes minimal budgeted amperage, enabling daisy-chain deployments across standard enterprise infrastructure. ONVIF compliance ensures vendor interoperability with third-party VMS platforms, protecting long-term software investment flexibility.
