Features:
AI
Frame Rate:
30 fps
Type:
Dome
Sensor Type:
Approx. 1/2.8 type CMOS image sensor
Scanning Area:
5.57 mm (H) × 3.13 mm (V)
Minimum Illumination:
0.0004 Lux (B&W, 16/30s)
White Balance:
ATW1 / ATW2 / AWC
Shutter Speed:
1/60 to 1/10000
Intelligent Auto:
On / Off
Super Dynamic:
On / Off, The level can be set in the range of 0 to 31.
Dynamic Range:
Max.144 dB (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back light compensation / High light compensation:
BLC/HLC adjustable 0-31
Fog compensation:
Fog compensation 0-8 levels
Maximum gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On / Auto1 / Auto2 / Auto3 (SCC)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off, 4 areas available
Scene Change Detection (SCD:
On / Off, 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Motion/Face/Vehicle Detection
Privacy Zone:
On / Off, Up to 32 zones available
VIQS:
On / Off, Up to 8 zones available
Image Stabilizer:
On / Off (Built-in gyro sensor)
Camera Title (OSD:
Configurable text, up to 40 characters
Focus Adjustment:
Auto focus
Optical Zoom:
21x (Motorized zoom / Motorized Focus)
Extra zoom:
Max. 31x (21 to 31x : When resolution is 1280 x 720)
Focal Length:
4.0 - 84.6 mm {5/32 inches - 3-21/64 inches}
Angular Field of View:
3.7°–77° horizontal (16:9), 2.9°–58° (4:3)
Maximum Aperture Ratio:
1 : 1.6 (WIDE) – 1 : 4.5 (TELE)
Focus Range:
1.5 m {50-1/16 inches} – ∞
Detect (25ppm / 8ppf:
Wide: 51.9m / 170.3 ft, Tele: 1293.8 m / 4244.9 ft
Observe (62.5ppm / 19ppf:
Wide: 20.8 m / 68.1 ft, Tele: 517.5 m / 1697.9 ft
Recognize (125ppm / 38ppf:
Wide: 10.4 m / 34.1 ft, Tele: 258.8 m / 849.0 ft
Identify (250ppm / 76ppf:
Wide: 5.2m / 17.0 ft, Tele: 129.4 m / 424.5 ft
System on Chip (SoC:
Ambarella CV25M
Adjusting Angle:
360° horizontal, -15° to +195° vertical
Panning Range:
360° Endless Panning
Panning Speed:
Manual: 0.065–150°/s; Preset: 500°/s
Tilting Range:
Operational -15 – +195°
Tilting Speed:
Manual: 0.065–150°/s; Preset: 500°/s (PoE+), 350°/s (DC12V)
Preset Positions:
256 positions
Auto Mode:
Auto track/ Auto pan/ Preset sequence/ Patrol
Self Return:
10s to 60min
Camera Control:
Brightness, AUX On / Off
Audio Support:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10 Base-T / 100 Base-TX, RJ45 connector
Resolution H.265/ H.264 JPEG (MJPEG:
1920x1080, 1280x720, 640x360, 320x180
H.265/H.264:
H.265/H.264, CBR/VBR, Unicast/Multicast
JPEG:
[Image Quality] 10 steps
Smart Coding:
GOP control: Off/Low/Mid/Advanced
Audio Compression:
G.726 (ADPCM) : 16 kbps / 32 kbps, G.711 : 64 kbps, +more
Audio Transmission Mode:
Off/Mic input/Audio output/Half duplex/Full duplex
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, SFTP, MQTT, LLDP; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v
No. of Simultaneous Users:
Up to 14 users (Depends on network conditions)
Secure:
FIPS 140-2 level 3 SecureElement, pre-installed cert
SDXC/SDHC/SD Memory Card (Option:
microSDXC memory card
Mobile Terminal Compatibility:
iPad, iPhone (iOS 8.0 or later), Android™ terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals, VMD, Command, Audio detection
Alarm Actions:
Email, HTTP, TCP notification, SD card recording
Audio Input:
3.5mm stereo mini jack
Audio Output:
3.5mm stereo mini jack, 600Ω
External I/O Terminals:
Alarm In x3, Alarm Out x1, Aux Out x1
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA),; ICES-003 Issue 7 ClassA,; EN55032 ClassA,; EN55035
Power Source and Power Consumption:
DC12V 1.3A / PoE 12.95W / PoE+ 18.4W
Ambient Operating Temperature:
-30°C to +55°C
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element
Water and Dust Resistance:
IP66
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS2(2.2.7-2.2.9)
Dimensions:
ø165 mm x 153 mm (H) {ø6-1/2 inches x 6-1/32 inches (H)}
Mass (Approx:
Approx. 1.7 kg {3.75 lbs.}
Finish:
Aluminum, polycarbonate, stainless steel
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE+
PoE Class:
0
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
2MP
Video Compression:
H.265, H.264, MJPEG
IR Distance:
1.5m
Built-in IR:
Yes
Day/Night:
Yes
Analytics:
Facial Recognition
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
Operating System:
Android
Image Stabilization:
Yes
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
3-year warranty
Poe Power:
PoE+ (802.3at)
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
4.0-84.6 mm (21x optical zoom)
Mount Type:
Wall; Ceiling; Rack
Camera:
Title (OSD) On / Off, Up to 40 characters (alphanumeric characters, marks)
Operating Temp:
-30 °C to +55 °C (-22 °F to +131 °F)
