i-PRO NVR-RL-1-48TB-V7 Tower Network Video Recorder
Overview
The NVR-RL-1-48TB-V7 is a pre-configured tower NVR built for mid-to-large commercial deployments running VideoInsight VI Server software. It ships with an Intel 6-core/12-thread Xeon processor, 32GB RAM, and 48TB total storage capacity — the fixed configuration means no assembly decisions, no integration delays. It handles 150–250 Mbps sustained recording rate, making it suitable for 20–40 concurrent HD or mixed-resolution camera streams depending on frame rate and codec selection. The unit arrives fully tested, with VI Server pre-installed and activated, plus ongoing VI software updates included for the warranty period.
Compatibility
This NVR is designed for VideoInsight VI Server environments and ONVIF-compliant IP camera systems. It integrates with any standard RTSP/ONVIF camera feed and third-party VMS platforms that support HTTP-based video ingestion. Verify your camera line supports ONVIF Profile S or T for seamless autodiscovery and credential management. The dual 1GB BASE-T network ports allow for redundant network paths or LAG (link aggregation) configuration in larger deployments.
Installation Notes
The tower footprint is compact (13.4″ H × 3.6″ W × 11.7″ D, 12 lbs) — designed for equipment racks or standalone desk placement. It draws 260W from the fixed internal PSU; ensure a dedicated 120V/240V circuit with UPS backup for 24/7 operation. The single 3.5″ HDD bay holds one enterprise-class drive; the M.2 slot hosts the OS and boot SSD (both pre-installed). No RAID controller is on-board — if redundancy is required, configure network-level mirroring or deploy a second NVR unit in parallel. The on-board TPM 2.0 chip enforces firmware signing and secure boot; Windows 11 PRO is pre-loaded and activated.
What's in the Box
- 1x NVR tower unit, fully configured and tested
- 1x 260W fixed power supply
- 1x VI Server software license (included, 1-year VI HM+ activation)
- 1x 3-year next business day on-site service contract (after remote diagnosis)
