i-PRO NVR-R-2-200TB-V7 Rack-Mount Network Video Recorder
Overview
The i-PRO NVR-R-2-200TB-V7 is a 2U rack-mount network video server built for large-scale surveillance deployments across campuses, municipalities, and multi-site enterprises. It pairs dual Intel Xeon Silver 12-core/24-thread processors with 64GB system RAM and 200TB native storage capacity—the core architecture needed to ingest, process, and retain hundreds to thousands of concurrent IP camera streams without performance degradation. Windows Server 2025 Standard Edition comes preloaded, reducing integration time and ensuring compatibility with third-party IP camera ecosystems and analytics platforms.
Compatibility
The NVR-R-2-200TB-V7 operates as a VideoInsight-based recording server and integrates with IP camera systems that support standard network streaming protocols. It is compatible with large-scale deployments utilizing ONVIF-compliant cameras and enterprise surveillance management platforms. The system supports recommended ingest rates of 300–600 Mbps (with RAID 5 configuration) or 600–1000 Mbps (with RAID 2), allowing flexible architecture around your camera bitrate and retention requirements. Dual 1GB BASE-T and dual 10GB SFP+ network interfaces provide scalable ingestion and redundancy options for multi-camera environments.
Installation Notes
The NVR-R-2-200TB-V7 ships fully configured and tested, requiring 4-post rack mounting. Dimensions are 3.41" height × 18.98" width × 28.4" depth (2U standard); confirm available rack space and thermal airflow before installation. The system draws dual 1100W power supplies (hot-swap capable), so provision two separate circuit branches or a redundant PDU to eliminate single points of failure during extended recording sessions. Rail kit is included; keyboard and mouse are not. RAID controller (H755) and iDRAC9 Express management are embedded—no additional configuration cards needed. Storage expansion via rear-mounted drives requires special order and extended lead time (14+ business days). Allow for remote diagnosis by i-PRO support prior to on-site service activation under the 5-year warranty.
What's in the Box
- 1x NVR-R-2-200TB-V7 fully configured 2U server
- 1x Rack rail kit (4-post)
- Documentation and quick-start guides
