i-PRO NVR-R-2-120TB-V7 Rack-Mount Network Video Recorder
Overview
The NVR-R-2-120TB-V7 is a 2U enterprise rack-mount network video recorder built for high-throughput surveillance deployments across campuses, healthcare facilities, education, and government installations. The unit packages dual Intel Xeon Silver 8-core processors, 64GB system RAM, and 120TB usable storage (configured as 6×20TB drives in RAID 5) into a compact rack form factor. This combination handles sustained multi-stream ingest from hundreds of IP cameras without processing bottlenecks, concurrent playback operations, and real-time metadata indexing—critical for organizations managing distributed camera networks with strict retention and compliance requirements.
Compatibility
The NVR-R-2-120TB-V7 operates as a Windows Server 2025 Standard Edition platform with VideoInsight (VI) Server preloaded and activated. It integrates with IP camera networks over dual 1GB BASE-T and dual 10GB SFP+ network interfaces, supporting scalable recording rates from 300–600 Mbps (recommended use case) up to 600–1000 Mbps on 10GB connectivity. The recorder accommodates up to 12×3.5" enterprise-class HDD bays (storage configurable at order time) and includes iDRAC9 Express for out-of-band server management. It is field-compatible with enterprise surveillance architectures using standard ONVIF or proprietary camera integrations where VI Server software acts as the video management backbone.
Installation Notes
The NVR-R-2-120TB-V7 mounts into standard 19" server racks as a 2U unit measuring 3.41" (H) × 18.98" (W) × 28.4" (D). Dual 1100W hot-swap power supplies provide N+1 redundancy; verify adequate rack PDU capacity and thermal management in your data center environment. The system includes redundant storage via onboard RAID controller (RAID 5 for multi-drive configurations or RAID 1 across M.2 SSD boot drives), TPM 2.0, and on-board encryption for data security. No monitor is included—manage via remote console or iDRAC interface. Allow 14+ business days for special order configurations. Unit weighs 63 lbs; confirm floor and rack loading limits before installation.
What's in the Box
- NVR-R-2-120TB-V7 fully configured and tested 2U rack-mount chassis
- Dual Intel Xeon Silver processors (pre-installed)
- 64GB RAM (pre-installed)
- 6×20TB enterprise HDD (pre-installed, RAID 5 configured)
- Dual 1100W hot-swap power supplies
- Windows Server 2025 Standard Edition (preloaded)
- VideoInsight Edition with 1-year VI HM+ Activation (preloaded)
- iDRAC9 Express management interface (embedded)
- Rack rails for 19" standard server racks
