i-PRO NVR-R-2-120TB-FD7 Rack-Mount Network Video Recorder
Overview
The i-PRO NVR-R-2-120TB-FD7 is a 2U rack-mount network video recorder built for enterprise deployments requiring sustained multi-stream ingest, hardware-level encryption, and federal compliance. With dual Intel Xeon Silver 8-core processors, 64GB RAM, and 120TB usable storage (from six 20TB enterprise drives in RAID 5), this unit handles 600–1000 Mbps concurrent recording rates across hundreds of simultaneous camera streams without throughput degradation. Ship it into data centers, campus surveillance infrastructures, or government facilities where storage retention, real-time playback, and forensic retrieval must coexist under compliance constraints.
Compatibility
The NVR-R-2-120TB-FD7 integrates with VideoInsight Edition video management server software (preloaded and activated) and supports ONVIF-compliant IP cameras across all major vendors — Axis, Hikvision, i-PRO, Hanwha, Vivotek, and others. The dual 1GB Ethernet and dual 10GB SFP+ ports scale to mixed-speed network architectures. Supports up to 12 hot-swap 3.5-inch enterprise HDD bays and can scale to 180TB total capacity within the same 2U form factor using the NVR-R-2-180TB-V8 variant. iDRAC9 Express out-of-band management integrates with enterprise IT asset-tracking and firmware-update workflows.
Installation Notes
Dimensions (without bezel): 3.41" H × 18.98" W × 28.4" D; weight 63 lbs — confirm rack rail capacity and PDU outlet proximity. Dual 1100W hot-swap power supplies require two separate 20A circuits or redundant PDU connections. Windows Server 2025 Standard is preloaded; allow network isolation during initial imaging if HIPAA, FedRAMP, or similar certification is required. TPM 2.0 and on-board encryption are active by default — no additional encryption appliances needed, but backup keys must be escrowed per your compliance regime.
What's in the Box
- 1x NVR-R-2-120TB-FD7 Fully Configured and Tested Unit
- 2x 1100W Hot-Swap Power Supply
- iDRAC9 Express Remote Management (Embedded)
- Rack Rails (Bezel Included)
- 1-Year VI HM+ Activation License
