HPE 868703R-B21#B19 DL380 G10 8SFF Reman Srv:eu-multi

HPE 868703R-B21#B19 DL380 Gen10 8SFF 2U Rack Server

Overview

The HPE 868703R-B21#B19 is a configure-to-order (CTO) 2U rack-mountable server built on the ProLiant DL380 Gen10 platform — HPE's dual-socket 2U workhorse for compute-intensive workloads where density, memory headroom, and redundant infrastructure matter. Shipped as a base chassis with no CPU, no RAM, and no drives installed, this unit is designed for integrators and IT architects who spec their own processor, memory, and storage profile. The 868703R-B21#B19 (often searched as 868703R B21#B19) supports up to two Intel Xeon Scalable processors in FCLGA3647 sockets on an Intel C621 chipset — covering entry Xeon Bronze through high-core-count Gold and Platinum configurations depending on your workload budget.

This is a refurbished/remanufactured unit sourced through HPE's own channel, carrying a 3-year next-business-day on-site limited warranty covering parts and labor — plus 90 days of software application support. For multi-site surveillance infrastructure, edge compute consolidation, or VMS server builds, this platform offers a proven, well-documented foundation without the lead times of new configure-to-order procurement.

Key Features

• Dual FCLGA3647 Socket Design: Two processor sockets on the Intel C621 chipset mean you can start with a single Xeon Scalable CPU and add a second later as workloads grow — relevant for VMS deployments that scale from 50 to 200+ camera channels without a forklift upgrade. Maximum processor speed reaches 3.9 GHz depending on the installed model.
• Up to 3 TB Load-Reduced ECC RAM across 24 DIMM Slots: Twenty-four DIMM slots (slots 13–24 active only in dual-processor config) support PC4-20800 / DDR4-2666 memory at up to 3 TB LRDIMM or 1.5 TB RDIMM. For video analytics platforms running deep-learning inference or large in-memory databases, 3 TB of ECC-protected memory is a ceiling most competing 2U platforms don't reach.
• 8x Hot-Swap 2.5" SFF Drive Bays: All eight SFF bays are hot-swappable, meaning you can swap a failed drive in a RAID array without taking the server offline — critical for 24/7 surveillance recording environments where downtime equals lost footage. No drives ship standard; configure your own SAS/SATA 2.5" media.
• HPE Smart Array S100i + Optional P408i-a / P816i-a: The base S100i is a software RAID controller over SATA 6Gb/s — fine for light workloads. For high-throughput VMS or tiered storage, slot in the P408i-a (8 internal ports) or P816i-a (16 internal ports) Smart Array controllers. The storage controller choice is the single biggest performance variable on this platform; plan this before ordering drives.
• HPE iLO 5 Remote Management: Integrated Lights-Out 5 gives you full out-of-band KVM, power control, and firmware update capability over a dedicated RJ-45 management port — without touching the production network. Combined with SNMP 3 and IPMI 2.0, iLO 5 fits into any enterprise monitoring stack. The dedicated iLO Type-A USB port on the front panel supports scripted provisioning via USB key.
• 4x Gigabit Ethernet (HPE 331i) + Optional FlexibleLOM: Four rear-facing GbE ports cover most VMS and NVR network topologies. The FlexibleLOM slot lets you upgrade to 10GbE or higher without consuming a PCIe expansion slot — relevant if you're aggregating high-bitrate streams from 4K camera banks or connecting to a 10G core switch fabric.
• 8 PCIe Expansion Slots: Eight expansion slots provide room for additional NICs, HBAs, GPU accelerators, or capture cards — consult the QuickSpecs for slot type/bandwidth per position. GPU-based video analytics acceleration requires verifying slot PCIe generation and available wattage from the power supply configuration.
• Optional 1+1 Redundant Power: Power redundancy is not included by default but is supported in a 1+1 configuration. For always-on security infrastructure, budget for the second PSU at build time — retrofitting it later requires a maintenance window. Input voltage is AC 100–240V, 50/60 Hz.
• FIPS 140-2, AES, TLS 1.2, TPM 2.0 Security Stack: The platform supports FIPS 140-2 validated cryptography, AES encryption, TLS 1.2, and optional TPM 2.0 via the Intrusion Detection and Locking Bezel Kit accessories. For federal, healthcare, or financial deployments with compliance requirements, these are the certifications to cite in your architecture documentation.
• ASHRAE A3/A4 Thermal Ratings: Rated for ASHRAE Class A3 (up to 40°C inlet) and A4 (up to 45°C inlet), this server tolerates warmer-than-standard data center environments — useful for closet deployments or edge sites without precision cooling. Operating range is 50°F–95°F (10°C–35°C) with 8–90% non-condensing humidity.
• MicroSD Internal Bay: The internal microSD slot supports HPE Intelligent Provisioning and boot media — keeps an OS image off your primary storage pool and simplifies bare-metal re-provisioning after a drive failure.

Integration & Compatibility

The DL380 Gen10 platform is broadly supported by enterprise VMS vendors including Milestone XProtect, Genetec Security Center, Axis Camera Station, and Exacq — verify your VMS vendor's server compatibility matrix for the specific Xeon Scalable generation you install. The HPE ProLiant DL380 Gen10 HPE server lineup integrates with HPE OneView and iLO Amplifier Pack for multi-node fleet management, relevant when deploying multiple units across distributed security operations centers.

For rack server builds targeting surveillance workloads, pair this chassis with HPE-branded or HPE-compatible DDR4-2666 RDIMMs, an HPE Smart Array P408i-a for RAID 5/6 protection across the 8 SFF bays, and dual hot-plug power supplies. Review the PoE switch infrastructure feeding your camera network separately — the DL380 is the recording/compute layer, not the edge layer. For storage planning on long-retention VMS deployments, a NAS or external storage array connected via the FlexibleLOM 10GbE port is the standard scale-out path once the 8 internal bays are saturated.

Frequently Asked Questions

Q: Does the HPE 868703R-B21#B19 ship with a CPU, RAM, or drives installed?

A: No. The 868703R-B21#B19 is a CTO (configure-to-order) base chassis. It ships with 0 GB RAM installed, no processors, and no drives. You must separately configure and order compatible Xeon Scalable CPUs (FCLGA3647), DDR4-2666 DIMMs, and 2.5" SFF drives.

Q: What is the maximum memory supported by the 868703R-B21#B19?

A: Up to 3 TB using Load-Reduced ECC DIMMs (LRDIMM) across 24 DIMM slots. Registered ECC (RDIMM) tops out at 1.5 TB. Note that slots 13–24 are only accessible in a dual-processor configuration.

Q: What warranty is included with the 868703R-B21#B19?

A: The unit includes a limited 3-year on-site warranty covering parts and labor with next-business-day response time, plus 90 days of software application support. This is the manufacturer warranty as listed in the product specifications.

Q: How many drive bays does the 868703R-B21#B19 have, and are they hot-swappable?

A: Eight 2.5" SFF hot-swap bays, all free from the factory. All eight support hot-swap replacement, which means you can replace a failed drive in a running RAID array without scheduling downtime.

Q: What remote management capabilities are built into the 868703R-B21#B19?

A: HPE Integrated Lights-Out 5 (iLO 5) is built in, accessible via a dedicated rear RJ-45 management port and front-panel USB Type-A iLO port. It supports SNMP 3, IPMI 2.0, and SMASH CLP for enterprise monitoring and out-of-band management without touching the production network.

Q: Is the 868703R-B21#B19 compatible with enterprise VMS platforms like Milestone or Genetec?

A: The DL380 Gen10 platform is widely used as a VMS recording server. Compatibility depends on the specific Xeon Scalable CPU and OS you install — verify against your VMS vendor's hardware compatibility list for the exact processor generation and Windows Server or Linux version you plan to deploy.

James Everett

The 868703R-B21#B19 is a DL380 Gen10 base chassis that I'd specifically recommend for integrators building out multi-channel VMS recording infrastructure where you need to control the CPU and storage tier precisely — the CTO model means you're not paying for a processor bundle that doesn't match your channel count and codec load. The 24 DIMM slots with 3 TB LRDIMM ceiling is the spec that sets this platform apart from competing 2U designs when you're running analytics-heavy workloads alongside recording.

Technical Highlights:

• 24 DIMM Slots / 3 TB Max LRDIMM: At DDR4-2666 (PC4-20800) speeds, a fully populated LRDIMM config gives analytics engines and in-memory indexing workloads room most 2U platforms reserve for 4U builds. Slots 13–24 require dual CPU — don't spec these slots without budgeting for the second processor.
• 8x Hot-Swap SFF Bays + Smart Array Options: The base S100i SATA controller is adequate for light recording; for multi-stream 4K VMS, install the P408i-a (8 internal ports, 12Gb/s SAS) to avoid controller-level bottlenecks. All 8 bays are hot-swap — zero downtime on drive replacement in a live recording environment.
• iLO 5 Out-of-Band Management: Dedicated management port keeps provisioning, firmware updates, and KVM access completely isolated from your camera/recording VLANs. For security operations deployments, this separation is an architecture requirement, not a nice-to-have.

Deployment Considerations:

• This unit ships with no CPU, no RAM, and no drives. Budget for a compatible FCLGA3647 Xeon Scalable, DDR4-2666 DIMMs in matched pairs per channel, and 2.5" SFF SAS/SATA drives before deploying — the chassis alone cannot POST without at minimum one CPU and one DIMM.
• Power redundancy is optional and not included. For any 24/7 security recording deployment, order the second hot-plug power supply at the same time as the chassis — retrofitting it later requires a planned outage to seat and configure the second PSU module.

This platform is the right call for a 50–200+ camera VMS recording node where the integrator needs full control over processor TDP, memory density, and storage controller — particularly in healthcare or government environments where FIPS 140-2 and TPM 2.0 compliance are mandatory checklist items at deployment sign-off.
