Panduit CMDRHD1 Concise Descriptor

Overview

The Panduit CMDRHD1 is a high-density horizontal D-ring designed for structured cabling installations. It provides a clean and organized pathway for cables within network racks and cabinets, preventing tangles and simplifying maintenance. This accessory is crucial for managing patch cords and horizontal cable runs in environments where space is at a premium, such as data centers and telecommunications rooms. The CMDRHD1 model specifically addresses the need for efficient cable routing in high-density rack configurations.

Compatibility

This D-ring is designed to integrate with standard 19-inch rack systems. It is compatible with Panduit's range of network racks and cabinets, including but not limited to the WMR, WMS, and NEMA series. It is suitable for use with various types of network cabling, including Cat5e, Cat6, Cat6a, Cat7, and fiber optic patch cords, ensuring broad applicability across different infrastructure deployments.

Installation Notes

The CMDRHD1 mounts to the front or rear of standard 19-inch racks using the provided hardware. Ensure the rack posts are clean and free of obstructions before installation. For optimal cable management, install rings at regular intervals (e.g., every 1U or 2U) to distribute cable load and prevent excessive strain on connectors. Torque mounting screws to manufacturer specifications to ensure a secure fit without damaging rack posts.
