Honeywell 1962GSR-2USB-5-N Xenon XP 1952g 1D/2D Area Imager Scanner

The Honeywell 1962GSR-2USB-5-N is an enterprise-grade area imager barcode scanner built for high-throughput retail, warehouse, and field service operations where durability and reliable multi-format barcode capture matter. Unlike laser scanners that require precise angle alignment, the area imager architecture in the Xenon XP 1952g reads both 1D linear codes (EAN, UPC, Code 128) and 2D matrix formats (QR, Data Matrix) without mechanical repositioning—reducing checkout friction and operator training overhead. IP65 environmental protection means dust and splash won't disable the scanner, and the proven 2.0 m (6.5 ft) drop rating handles typical warehouse floor abuse without premature failure. Bluetooth 4.2 wireless connectivity eliminates checkout counter cable clutter while preserving USB compatibility with legacy point-of-sale infrastructure.

Key Features

• Area Imager 1D/2D Capture: Reads linear barcodes (EAN, UPC, Code 128) and matrix codes (QR, Data Matrix) without manual barcode rotation—speeds throughput on fast checkout lines and reduces misread rejects during receiving operations.
• IP65 Environmental Rating: Sealed against dust ingress and low-pressure water jets, so the scanner tolerates wet warehouse floors, outdoor loading docks, and ambient moisture without enclosure or protective housing—a real cost saver when deploying across multiple environments.
• 2.0 m Drop Protection: Survives accidental floor drops during shift changes and sorting operations; eliminates the need for expensive rugged protective cases on every unit in a high-turnover warehouse environment.
• Bluetooth 4.2 Wireless + USB Fallback: Wireless deployment reduces infrastructure cost (no PoE or RS-232 runs to each checkout station), while USB compatibility ensures operation on systems predating wireless networks—avoids forced hardware upgrades.
• 2.5 to 50.8 cm Working Range (1 to 20 inches): Accommodates both close-proximity checkout scanning and mid-distance inventory bin reads; operators don't need to force barcodes right against the optics, reducing hand fatigue over extended shifts.
• Multi-Symbology Decoder: Natively supports EAN, UPC, Code 128, QR Code, and Data Matrix in a single device—eliminates the need for separate barcode type-specific scanners when moving goods across different supply chain partners or geographies.

Typical Deployment Scenarios

The 1962GSR-2USB-5-N excels in moderate-duty retail and warehouse environments. Point-of-sale operators benefit from the area imager's lack of angle sensitivity—customers can hand you a barcode at any orientation, and the scanner captures it on the first pass. Warehouse receiving teams use the 2.5–50.8 cm range to scan both small package labels (close range) and pallet tags (extended range) without switching devices. Shipping and logistics operations integrate the Bluetooth connectivity into mobile carts and handheld route terminals. Asset tracking and fixed-asset cycle counts rely on the multi-symbology support to read legacy asset tag formats alongside newer QR-based inventory systems. The IP65 rating keeps the scanner operational in temperature-controlled cold storage, outdoor loading docks, and high-humidity pharmaceutical environments—no special ventilation or climate control required.

Integration & Connectivity

The 1962GSR-2USB-5-N (often searched as 1962GSR 2USB 5 N) pairs with standard warehouse management, retail point-of-sale, and asset management systems via Bluetooth 4.2 or USB-HID. Bluetooth 4.2 power efficiency means multi-day operational battery life in typical shift patterns—a practical advantage over older RF protocols that drain batteries after 8–12 hours. USB connectivity works on any standard Windows, macOS, or Linux endpoint without drivers on most platforms, accelerating deployment across mixed-OS retail chains. The scanner outputs barcode data as keyboard input, so legacy systems expecting barcode data from a hand-held keyboard wedge require no middleware or API customization.

Frequently Asked Questions

Q: What happens if I use the 1962GSR-2USB-5-N beyond the 50.8 cm working range?

A: Read accuracy degrades beyond 20 inches. For pallet scanning at extended distances (beyond 2 feet), consider a long-range variant in the Xenon XP family designed for 80+ cm capture. For standard checkout and receiving, the 1–20 inch range meets typical workflow.

Q: Does the 1962GSR-2USB-5-N support 2D matrix codes only, or can it read linear 1D barcodes as well?

A: The area imager reads both. It natively decodes EAN, UPC, and Code 128 (1D linear formats) alongside QR and Data Matrix (2D formats) in a single scan without configuration changes.

Q: Is IP65 enough protection for outdoor use, or do I need IP67?

A: IP65 protects against rain, splash, and dust blown into the enclosure—sufficient for covered loading docks and outdoor awnings. IP67 (full submersion) isn't needed unless the scanner will be dunked in water. For open-air outdoor scanners or wet-floor food service environments, verify the water spray pattern matches your site conditions.

Q: Can I pair multiple 1962GSR-2USB-5-N units to a single Bluetooth receiver, or do I need separate receivers?

A: Bluetooth 4.2 pairs a scanner one-to-one with a terminal or receiver. High-throughput checkout environments typically use one scanner per station; verify your POS receiver supports rapid multi-device reconnection if you're rotating scanners between stations.

Q: How often do I need to replace the scanner's battery on a typical retail shift?

A: Bluetooth 4.2 modern power efficiency delivers multi-day battery life in typical 8–10 hour shifts. Check the technical datasheet for precise battery capacity and power budget; spare batteries are a best practice for high-volume retail environments.

Q: What's the temperature operating range for the 1962GSR-2USB-5-N?

A: Verify in the technical datasheet; common industrial barcode scanners operate 0°C to 50°C (32°F to 122°F). Cold storage environments (below 0°C) may require extended warm-up time. Contact the manufacturer or your integrator for specific temperature certifications if deploying in refrigerated warehouses.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The 1962GSR-2USB-5-N strikes an effective balance between ruggedness and flexibility for general-purpose retail and warehouse scanning. The area imager architecture eliminates the training friction associated with laser-based scanners that demand precise barcode alignment—any operator can hand a customer receipt to the device at any angle, and the scanner captures it cleanly. IP65 protection plus a 2.0 m drop rating together mean this device handles typical warehouse floor abuse without requiring expensive protective enclosures on every unit.

Technical Highlights:

• Area Imager 1D/2D Capture: No mechanical scanning head, no stepper motors—reads 1D codes (EAN, UPC, Code 128) and 2D formats (QR, Data Matrix) natively without rotation or repositioning, improving first-pass read rates in fast-paced checkout lines.
• IP65 + 2.0 m Drop Rating: Sealed enclosure handles dust and splash; survived drops to 6.5 feet without protective case—reduces total cost of ownership when deploying 50+ units across warehouses with moisture and rough handling.
• Bluetooth 4.2 Wireless: Modern power efficiency delivers multi-day battery runtime on typical shifts, while USB fallback preserves compatibility with legacy point-of-sale systems—no forced infrastructure upgrades.
• 2.5–50.8 cm Working Range: Handles both close checkout scanning and mid-distance bin label reads without operator neck strain or barcode repositioning—a practical benefit in high-volume retail environments.

Deployment Considerations:

• Range is limited to 20 inches maximum. If your warehouse requires pallet-level scanning beyond 3 feet, this is not the right model—evaluate extended-range variants in the Xenon XP family.
• Bluetooth 4.2 pairs one scanner to one receiver. In environments with rapid scanner rotation between checkout stations, verify your POS system supports fast re-pairing or maintain a scanner per station.

The 1962GSR-2USB-5-N is well-suited for retail chains consolidating multiple barcode format readers into a single multi-symbology device, warehouse receiving teams operating in moisture-prone environments, and logistics operations deploying wireless-enabled handheld scanning carts. Skip this model if your workflow requires pallet-distance scanning or operates in extreme temperature environments below 0°C.
