IP Video Input:
32-ch;Up to 32 MP resolution;*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Incoming Bandwidth:
320 Mbps
Outgoing Bandwidth:
400 Mbps
HDMI 1 Output:
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz
HDMI 2 Output:
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz;*: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
VGA Output:
1920 × 1080/60Hz
Video Output Mode:
HDMI1/VGA simultaneous output, HDMI2/VGA independent output
CVBS Output:
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Audio Output:
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio:
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding Format:
H.265+/H.265/H.264+/H.264
Recording Resolution:
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF;*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Synchronous Playback:
16-ch
Decoding Capability:
2-ch@32 MP (30 fps)+2-ch@8MP（30fps）/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps)
Dual-Stream Recording:
Support
Stream Type:
Video, Video & Audio
Audio Compression:
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2
Remote Connection:
128
Network Protocol:
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface:
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Interface:
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power:
≤ 200 W
Standard:
IEEE 802.3 af/at
RAID Type:
N/A
ESATA:
1 eSATA interface
SATA:
4 SATA interfaces
Capacity:
Up to 16 TB capacity for each HDD
Serial Interface:
2 RS-485 (half-duplex), 1 RS-232
Alarm In/Out:
16/9
USB Interface:
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Ctrl 12V:
Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.;*: The Ctrl 12V power is controlled by alarm output 9.
DC 12V:
12 VDC, 1 A power output
Power Supply:
100 to 240 VAC, 50 to 60 Hz
Consumption:
≤ 15 W (without HDD and PoE off)
Working Temperature:
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity:
10% to 90%
Chassis:
19-inch rack-mounted 1.5U chassis
Dimension (W × D × H:
445 × 400 × 75 mm ( 17.5"× 15.7" × 3.0")
Weight:
≤ 5 kg (without HDD, 11 lb.)
FCC:
Part 15 Subpart B, ANSI C63.4-2014
CE:
EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
