Type:
Dome
Frame Rate:
Standard
Sensor Type:
1/2.8" CMOS Progressive Scan
Min. Illumination:
0.01 Lux
Resolution:
2MP
Shutter Speed:
1/3 s to 1/100,000 s
P/N:
PAL: 25fps;NTSC: 30fps
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan:-30°~+30°, Tilt: 0°~75°, Rotate: 0°~ 360°
White Balance:
Manual/Auto, 4 presets
Focal Length:
2mm/2.8mm/4mm/6mm/8mm
Focal Length & FOV:
2/2.8/4/6mm, FOV 132°/105°/87°/53°
Lens Mount:
M12
Focus:
Manual focus
Max. Aperture:
2mm: F2.25;2.8mm/4mm/6mm/8mm: F1.6
Supplement Light Type:
Infrared fill light lamp
Smart Supplement Light:
Support
IR Wavelength:
850 nm
IR Distance:
Up to 10 m
Max. Resolution:
1920 × 1080
Main Stream:
1920×1080 @ 25fps
Sub-Stream:
704×576 @ 25fps
Third Stream:
1920×1080 @ 25fps
Video Compression:
Main stream: H.264, H.265, H.264+, H.265+, +more
Video Bit Rate:
256 Kbps to 12 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
Constant Bit Rate, Variable Bit Rate
Stream Type:
Main stream, sub stream, third stream
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
Support 2 fixed region for (main/sub) stream
Audio Compression:
G711U, G711A, G726, AAC, G722, PCM, AAC
Audio Bit Rate:
64 Kbps
Audio Sampling Rate:
16 kHz
Environment Noise Filtering:
Support
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, Email, RTP, RTSP, RTCP, NTP, UPnP, SMTP,SNMP, ICMP 802.1X, QoS, IPv6, Bonjour, ISUP5.0
Simultaneous Live View:
Up to 8 channels
API:
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
User Management:
Up to 16 users, 3 levels: Administrator, Operator and User
Web Browser:
IE8+, Chrome45+, Edge41+, Firefox45+
Wide Dynamic Range (WDR:
120 dB
Image Settings:
Support rotation mode. Brightness, contrast, saturation and sharpness can be adjusted by browser and client software.
Day/Night Switch:
Day/Night/Auto/Schedule
SNR:
> 50 dB
Image Enhancement:
BLC, HLC, 3D DNR
Privacy Mask:
Enables configuration, and supports drawing of up to 4 areas
Picture Overlay:
Support image overlay, uploading images, enabling, coordinates, etc.
Target Cropping:
Support (only the third stream)
Backlight Compensation(BLC:
Support up/down/left/right/center/custom
Video Outputs:
Not supported
Ethernet Interface:
1x RJ45 10/100M, 1x M12 4-pin
SD Card Storage:
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Audio Support:
1 built-in mic, mono sound
Reset Key:
Support
Interface Type:
Interpolate
People Density:
Support the detection of passenger congestion in carriages.
Detection:
Detection of left articles/personnel
Linkage Method:
FTP/Email/Recording Alert
Basic Event:
Motion detection, video tampering alarm
Smart Event:
Line crossing detection, Intrusion detection, Region entrance detection, Region exiting detection, Unattended baggage detection, Object removal detection, Object detection: detects faces and upload images;Scene change detection, defocus detection
Product Dimension:
110 mm × 57.4 mm (4.3" × 2.26")
Package Dimension:
252 mm × 160 mm × 95 mm (9.9" × 6.3" × 3.7")
Product Weight:
Approx. 452 g (1 lb.)
With Package Weight:
252 mm × 160 mm × 95 mm (9.9" × 6.3" × 3.7")
Protection:
IP67, IK10
Camera Material:
Metal
Startup And Operating Conditions:
-30°C to 75°C
Language:
English, French, German, Russian, Italian, +more
General Function:
Anti-flicker, heartbeat, mirror
Software Reset:
Support
Power Type:
PoE
Power Interface:
PoE, DC coaxial, or M12 connector
Cable Length:
50 cm
Class:
Class B
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013);
Environment Rating:
CE-RoHS (2011/65/EU);
Electrical Safety Protection:
IK10(IEC 62262:2002)
Automotive And Railway:
EN50155:2017, EN45545-2:2013, ECE R10
Product Type:
Dome
Connectivity:
Wired
Night Vision:
IR
Housing Color:
White
Warranty:
5-year warranty
