Image Sensor:
1/2.8" Progressive Scan CMOS
Max. Resolution:
1920 × 1080
Min. Illumination:
Color: 0.002 Lux @ (F1.6, AGC ON)
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens Type:
2.0/2.8/4/6/8 mm fixed lens
Focal Length & FOV:
2 mm, horizontal FOV 132.8°, vertical FOV 77.6°, diagonal FOV 151.5°;2.8 mm, horizontal FOV 108°, vertical FOV 59.3°, diagonal FOV 128.9°;4 mm, horizontal FOV 82.8°, vertical FOV 45.1°, diagonal FOV 98°;6 mm, horizontal FOV 52.7°, vertical FOV 30.3°,
Lens Mount:
M12
Aperture:
2 mm, F2.25, 2.8/4/6 mm, F2.0, 8 mm, F1.6
Supplement Light Type:
IR
Supplement Light Range:
Up to 30 m
IR Wavelength:
850 nm
Main Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720);60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream:
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240);60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream:
50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288);60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264;Sub-stream: H.265/H.264/MJPEG;Third stream: H.265/H.264
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region for main stream and sub stream
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate:
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8Kbps-320Kbps(MP3)
Audio Sampling Rate:
8kHz/16kHz/32kHz/44.1kHz/48kHz
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
microSD/SDHC/SDXC card (up to 128 GB), local storage and NAS (NFS,SMB/CIFS), ANR;Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11;Plug-in free live view: Chrome 45+, Mozilla Firefox52+
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Day/Night Switch:
Day/Night/Auto/Schedule
Wide Dynamic Range (WDR:
120 dB
Image Enhancement:
BLC, HLC, 3D DNR
Ethernet Interface:
1 RJ45 10M/100M Ethernet port
On-Board Storage:
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Audio:
1 built-in mic, mono sound
Alarm:
-S: 1 input, 1 output (12 VDC, 30 mA)
Reset Key:
Yes
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, up to 1 line configurable;Intrusion detection, up to 1 region configurable;Unattended baggage detection, up to 1 region configurable;Object removal detection, up to 1 region configurable;Face detection: detects faces and uplo
Linkage:
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
Power:
-IDS: 24 VDC is recommended, support 8 to 36 VDC, 0.3 A, max. 7.5 W, Ø5.5 mm coaxial power plug;-IS/ND: PoE: 802.3af, Class 3, 36V to 57V, 0.30 A to 0.20 A, max. 7.5W;-IDM: 24 VDC is recommended, support 8 to 36 VDC, 0.3 A, max. 7.5 W, two-core molex
Dimension:
Ø110 mm × 57.4 mm (4.3" × 2.26"), with base: Ø110 mm × 69.4 mm (4.3" × 2.7")
Package Dimension:
252 mm × 160 mm × 95 mm (9.9" × 6.3" × 3.7")
Weight:
Approx. 460 g (1 lb.)
With Package Weight:
Approx. 900 g (2 lb.)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing)
Language:
32 languages;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditiona
General Function:
Anti-flicker, 3 streams, heartbeat, mirror, privacy mask
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IP67(IEC 60529-2013), IK10(IEC 62262: 2002)
Automotive And Railway:
EN 50155-2017: EN 50155: 2017;EN 50121-3-2: 2016;IEC 60068-2-1: 2007;IEC 60068-2-2: 2007;IEC 60068-2-30: 2005;IEC 61373: 2010;EN 45545: EN 45545-2:2013+A1: 2015;E-MARK: ECR R10
Environment:
CE-RoHS (2011/65/EU);WEEE (2012/19/EU);Reach (Regulation (EC) No 1907/2006)
Automotive and Railway:
EN 50155-2017:EN 50155: 2017EN 50121-3-2: 2016IEC 60068-2-1: 2007IEC 60068-2-2: 2007IEC 60068-2-30: 2005IEC 61373: 2010EN 45545: EN 45545-2:2013+A1: 2015 E-MARK: ECR R10
