Frame Rate:
30fps
Sensor Type:
1/2.7" Progressive Scan CMOS
Min. Illumination:
0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
ICR Cut
Linkage Method:
FTP/NAS/Email/Alarm/Recording
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Focus:
Fixed
Lens Type & FOV:
1.68mm F2.0, 180° FOV
Aperture:
F2.0
Lens Mount:
M12
DORI:
Detect 3.6m / Observe 1.4m / Recognize 0.8m
IR Distance:
20 m
Wavelength:
850nm
Smart Supplement Light:
Yes
Max. Resolution:
2688 × 1520
Main Stream:
25fps @ 2688×1520 (50Hz) / 30fps @ 1920×1080 (60Hz)
Sub Stream:
25-30fps, 320×240 to 640×480
Video Compression:
H.265+/H.265/H.264+/H.264, Sub: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Stream Type:
Main stream, Sub-stream
Scalable Video Coding (SVC:
H.264, H.265
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host:
Up to 32 users;3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
micro SD/SDHC /SDXC (256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Chrome 45+, Firefox 52+
Day/Night Switch:
Day, Night, Atuo, Schedule
Image Enhancement:
BLC;HLC;EIS;Lens Distortion;3D DNR
Image Settings:
Saturation;brightness;contrast;sharpness;rotate mode;white balance;AGC
SNR:
≥ 50 dB
Privacy Mask:
4 regions of privacy mask
On-Board Storage:
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Smart Event:
Line crossing detection, intrusion detecction, unattended baggage detextion, object removal detection, face detection, scene change detection
Web Client Language:
32 languages supported
General Function:
privacy mask;heart;mirror;flash log;password reset via e-mail;pixel counter
Storage Conditions:
-30°C to 60°C, ≤95% humidity
Startup And Operating Conditions:
-30°C to 60°C, 95% humidity max
Power Type:
12 VDC ± 25%; PoE: 802.3af, Class 3
Power Consumption And Current:
7.2W (12V) / 8.7W (PoE)
Power Interface:
Φ5.5 mm coaxial power plug
Material:
Metal
Camera Dimension:
Camera: Φ105 × 278 mm (Φ4.1" × 10.9")
Package Dimension:
386 × 156 × 155 mm (15.20" × 6.14" × 6.10")
Camera Weight:
570 g (1.26 lb.)
With Package Weight:
760 g (1.68 lb.)
Class:
Class B
Protection:
IP67
EMC:
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Environment Rating:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Housing Color:
White
