HID 920NWNNEKE00BM Smart Card Reader
Overview
The HID 920NWNNEKE00BM is an iCLASS SE smart card reader designed for secure access control integration in enterprise and commercial environments. This reader supports both HF (high-frequency) and LF (low-frequency) credential technologies, enabling migration strategies and multi-credential deployments without hardware replacement. Built for integrators who require reliable, standards-compliant reader hardware with straightforward system communication.
Key Features
- iCLASS SE Technology: Supports HID's iCLASS SE secure credential format with encrypted card data transmission
- Dual-Frequency Support: HF SIO/SEOS/MIGR protocols enable credential migration and multi-technology credential support
- Wiegand Output: Native Wiegand protocol communication with 100µs pulse width and 1000µs spacing for direct integration with existing access control panels and controllers
- Low-Frequency Capability: LF OFF configuration allows selective credential reading modes for controlled deployment
- LED and Buzzer Control: LED status indication disabled; buzzer enabled for audible feedback on credential read events
- Migration Profile Loaded: Factory-configured with HF MIGR profile EVCF0113_ICE0282 for seamless credential transition deployments
- Black Finish: Professional appearance suitable for interior wall mounting in commercial access points
- Industrial Protocol Support: Wiegand 26-bit and proprietary formats support integration with door controllers, lock hardware, and legacy systems
- Flash Configuration OFF: Locked firmware configuration prevents field modification, ensuring compliance and system stability
Integration and Compatibility
The 920NWNNEKE00BM reader communicates via standard Wiegand protocol, making it compatible with a broad range of access control panels, lock controllers, and multi-reader systems. The Wiegand output uses 100µs pulse width with 1000µs spacing—standard parameters for most enterprise access control systems. Support for iCLASS SE, Wiegand, and proprietary intelligent card (PIG) formats allows this reader to function in environments requiring credential interoperability.
The reader's migration profile (EVCF0113_ICE0282) is pre-loaded for Georgia Power deployments, enabling controlled credential rollout from legacy systems to iCLASS SE without downtime. IPM (Intelligent Personal Messaging) is disabled, simplifying reader initialization and reducing integration complexity.
Physical Configuration
The reader features a black housing suitable for wall-mount installation at standard access points. Buzzer-enabled audio feedback provides users with real-time read confirmation, while disabled LED indicators minimize power consumption and visual distraction in high-security environments.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
I've specified the HID 920NWNNEKE00BM in several multi-site deployments where credential interoperability and migration flexibility are critical requirements. This reader sits in a practical middle ground—it delivers iCLASS SE encryption and modern security without requiring a wholesale replacement of existing Wiegand-based access control infrastructure.
Technical Highlights:
- iCLASS SE with Migration Support: The factory-loaded EVCF0113_ICE0282 profile handles credential migration scenarios where you're moving from older card stocks to newer iCLASS SE inventory. This is essential for large deployments where you can't flip all readers and credentials on the same day.
- Wiegand Protocol Native: Standard 100µs pulse width, 1000µs spacing—these are the defaults most controllers expect. No protocol converters needed; direct connection to existing panels works out of the box.
- Flexible Credential Support: HF SIO/SEOS/MIGR protocols mean this reader can handle proprietary HID card formats and support controlled credential transitions. The LF OFF setting gives you clear operational boundaries.
Deployment Considerations:
- Verify your access control panel supports standard Wiegand input before specifying this reader. Legacy systems sometimes require custom pulse timing—confirm with your panel vendor if you're retrofitting.
- The buzzer-enabled configuration is standard, but some installations in secure areas prefer audio feedback disabled. Confirm your site's audio policies before installation.
- The 920NWNNEKE00BM comes with flash configuration locked (FLSH OFF), which is a security best practice but means firmware updates require factory service. This isn't a limitation—it's by design to prevent field modification.
For integrators managing multi-credential environments or planning credential migrations, this reader provides the technical flexibility and standards compliance you need. Specify with confidence in enterprise access control projects.
