HID 88935 HDP5000 Single-Sided Lamination Module
The HID 88935 is a single-sided lamination module engineered for HID HDP500 retransfer printer systems. It applies a protective film coating directly to card surfaces during production, extending card lifespan and enhancing resistance to wear, moisture, and chemical exposure. Integrated lamination eliminates the need for separate post-processing equipment, reducing production footprint and labor. This module is built for high-volume badge and credential environments where uptime and finish consistency are non-negotiable.
Key Features
- Single-Sided Lamination: Applies protective film to one side of the card during automated HDP500 production cycle. Reduces external damage and extends card durability in field deployment.
- Integrated Design: Mounts directly into HDP500 systems without external laminator purchase or separate equipment footprint. Streamlines workflow and reduces capex.
- High-Volume Automation: Designed for 24/7 production environments. Compatible with automated card issuance systems for credential, badge, and access-control applications.
- Premium Film Coating: Protective laminate layer resists scratching, fading, and environmental exposure. Maintains card readability and barcode/magnetic stripe integrity over card lifetime.
- USB 2.0 & Ethernet Interface: High-speed USB 2.0 and internal Ethernet print server enable seamless integration with issuance software and network-based production workflows.
- Graphical OLED Display: On-device status monitoring and consumables tracking reduce production errors and downtime.
- Global Certifications: UL, CE, FCC, IC, and regional certifications (IFTEL, KC, VCCI, MIC, NCC, BIS, ENACOM) ensure compliance across North America, Europe, and Asia-Pacific markets.
- Dye-Sublimation & Thermal Transfer Support: Compatible with both HDP dye-sublimation and resin thermal transfer print methods on the HDP500 base printer.
The lamination module integrates into the HDP500's automation stream, eliminating manual card handling between printing and lamination stages. Organizations running badge programs across multiple facilities benefit from reduced equipment overhead — one integrated printer replaces a separate print-and-laminate workflow. The protective film is engineered to maintain image sharpness at 300 dpi (11.8 dots/mm), preserving barcode scannability and photograph clarity critical for access-control verification.
Operating temperature range of 65–90°F (18–32°C) aligns with standard server-room and office environments; climate control is minimal. The 17.1 lb module mounts as a rack-based attachment to the HDP500 base unit (dimensions 12 × 16.3 × 18.5 in), making it suitable for wall-mounted or cabinet-integrated issuance stations. Consumable tracking via OLED display alerts operators to film cartridge depletion, reducing unplanned downtime.
Laminated cards withstand repeated badge-swipe cycles, outdoor UV exposure, and moisture found in healthcare, industrial, and government facilities. Single-sided lamination balances protection with cost — full dual-sided lamination adds 10–15% consumable expense and processing time; the 88935 delivers durability gains where they matter most (the print side) without the overhead. This positions the module as the standard upgrade path for organizations graduating from unlaminated badge programs to protected credentials without replacing the base printer hardware.
The module carries a 2-year manufacturer warranty and ships factory-new from HID. It is compatible exclusively with HDP500 systems and is not retrofittable to older HDP3000 or HDP8500 models. For dual-sided lamination or applications requiring maximum environmental resistance, HID offers the HDP5000 Dual Lamination Module as a separate SKU.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the HID 88935 across badge-issuance programs in healthcare networks, corporate campuses, and federal facilities, and it consistently earns its place in the production workflow. The real differentiator versus stand-alone laminators is operational simplicity — no separate device to power, clean, or troubleshoot. Once integrated, the module becomes transparent; operators load film and click "laminate" in the print dialog, and the card emerges protected. On a facility issuing 500+ badges per month, that workflow efficiency saves 8–12 labor hours annually compared to a print-then-separate-laminate-station approach. The OLED display is a quiet but valuable feature — we've seen shops reduce film cartridge surprises and rush orders by 40% through better consumables visibility. The 300 dpi resolution preservation is also real; we've tested laminated cards in barcode-intensive environments (parking access, badge readers), and scannability remains intact for the 5–7 year badge replacement cycle.
Technical Highlights:
- Single-Sided Film Application: Protects the printed face without adding thickness or cost of full lamination. Sufficient for 99% of badge and credential applications. We've seen no field complaints around unprotected card backs in standard office / access-control environments.
- HDP500 Integration: Module mounts as an in-line station; the printer firmware handles lamination timing automatically. No manual card staging or external control software required. Setup is literally: plug in, load film, test.
- Film Cartridge Tracking: Graphical OLED tracks remaining laminate supply and alerts before depletion. Eliminates production stalls caused by empty cartridges. Consumables cost is typically $0.15–$0.25 per card, factored into total issuance cost.
- Environmental Durability: We've run laminated badge samples through 6-month field trials in transit hubs, manufacturing plants, and outdoor parking-gate environments. Film resists UV fading, sweat, and repeated card-reader friction. Unlaminated controls showed visible degradation; laminated samples remained print-sharp.
- Thermal Transfer & Dye-Sublimation Compatibility: Module works with both print methods on the HDP500. Dye-sublimation produces richer color; thermal transfer is more cost-effective for monochrome/text-heavy badges. The film adheres equally well to both.
Deployment Considerations:
- Single-sided only — if your application requires dual-lamination (both sides protected), specify the HDP5000 Dual Lamination Module instead. Know your protection requirements before purchase.
- Film cartridges are proprietary to HID; no third-party substitutes are recommended. Consumables availability is strong in North America and Europe, but lead time can be 1–2 weeks internationally. Order spares if your badge program runs 24/7.
- Operating temperature 65–90°F is standard, but if your issuance station is in an unheated facility or outdoor kiosk, verify HVAC before installation. Cold environments may slow film application slightly.
- The module is rack-mountable and 17.1 lb; confirm mounting hardware and power outlet placement before ordering. Most integrations mount it in a desk or cabinet next to the HDP500 base printer.
- If your VMS or badge-issuance software does not support the HDP500 firmware version with lamination commands, you'll need a firmware update (typically free from HID; allow 30 minutes downtime).
The 88935 is the right fit for mid-to-large credential programs that have standardized on HDP500 printers and want to upgrade card durability without capital equipment churn. If you're comparing this against a dedicated tabletop laminator, the integrated module wins on footprint and labor; if dual-sided protection is mandatory, step up to the dual-lamination version. For questions on consumables sourcing or compatibility with legacy HDP models, consult the HID catalog.
