HES CBL6-QC12 K200/KS200 Lock Interface Cable

12-conductor cable for HES K200/KS200 locks, 6 feet with Molex connectors

$45.99
Special Order
Usually Ships in 2-3 Weeks

Quantity:

Adding to cart… The item has been added
Compatibility guidance available for your deployment
Experts for pre and post-sales support
Technical and documentation support
Shipping and lead-time confirmation before install
Laura Bennett, IPSD Senior Specialist

Talk to Laura

Specialized training • U.S - based

Senior Specialist • 877-277-7147

Message Call

HES CBL6-QC12 K200/KS200 Lock Interface Cable

$45.99
Add to Cart

Overview

SKU: CBL6-QC12
UPC: 740090025063
Condition: New
Availability: Special Order · Usually Ships in 2-3 Weeks

No Bots, Just Experts

Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.

Get Free Pre-Sales Support Buy Design Hours ($175/hr)
Description

HES CBL6-QC12 K200/KS200 Lock Interface Cable

The HES CBL6-QC12 is a purpose-built 12-conductor interface cable designed to connect HES K200 and KS200 electromagnetic lock systems to access control panels and power management hardware. This 6-foot cable provides reliable signal and power transmission between lock mechanisms and control interfaces in professional access control installations.

Key Features

  • 12-conductor configuration for complete signal and power routing
  • 6-foot length suitable for standard door frame installations
  • Molex connectors on both ends for secure, keyed connections
  • Prevents installation errors through keyed connector design
  • Industrial-grade construction for access control environments
  • Compatible with HES K200 and KS200 electromagnetic locks

Technical Specifications

  • Conductor Count: 12-conductor
  • Cable Length: 6 feet
  • Connector Type: Molex (both ends)
  • Form Factor: Cable assembly
  • Compatible Systems: HES K200, HES KS200

Applications

Ideal for commercial access control installations including office buildings, data centers, secure facilities, and institutional environments where K200/KS200 locks are deployed. The cable's industrial-grade design and keyed connectors make it essential for installations requiring reliable, error-free connections between lock hardware and control systems.

Expert Analysis
Specifications
length: 6 feet
conductors: 12-conductor
Compatible With: HES K200, HES KS200
Form Factor: Cable
Connector Type: Molex
Type: Cable
