Type:
PTZ
Frame Rate:
60fps
Imaging Device:
1/2.8" CMOS
Resolution:
1920x1080
Max. Framerate:
60fps
Min. Illumination:
0.05 Lux color / 0 Lux IR
Video Out:
None
Focal Length (Zoom Ratio:
4.25~170mm(40x) zoom (digital 32x, total 1280x zoom)
Max. Aperture Ratio:
F1.6(Wide)~F4.95(Tele)
Angular Field of View:
H: 65.66˚(Wide)~1.88˚(Tele) / V: 39.40˚(Wide)~1.09˚(Tele)
Min. Object Distance:
3m(9.84ft)
Focus Control:
Oneshot AF, Focus save
Lens Type:
DC auto iris
Pan Range:
360˚ Endless
Pan Speed:
Max. 500˚/sec, Manual: 0.024˚/sec~250˚/sec
Tilt Range:
110˚(-20˚~90˚)
Tilt Speed:
Max. 350˚/sec, Manual: 0.024˚/sec~250˚/sec
Sequence:
Preset, Swing, Group, Trace, Tour, Auto Run, Schedule
Preset Accuracy:
±0.1˚, Pan/Tilt correction
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)/Color/BW/Schedule
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
Extreme WDR(150dB)
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, polygonal Support - Color: Grey/Green/Red/Blue/Black/White - Mosaic
Gain Control:
Manual / Max
White Balance:
ATW /Narrow ATW /AWC /Manual /Indoor /Outdoor /Mercury /Sodium
LDC:
None
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror
Analytics:
Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Shock detection * Audio detection, Sound classification(with NW I/O Box)
Business Intelligence:
None
Serial Interface:
None
Alarm Inputs/Outputs:
None
Alarm Triggers:
Analytics, Network disconnect * Alarm input(with NW I/O Box)
Alarm Events:
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers PTZ Preset Handover * Alarm output(with NW I/O Box)
Audio In:
None
Audio Out:
None
IR Viewable Length:
200m(656.17ft), Wise IR
IR Illuminator (Optional:
None
Water Removal:
Support(with wiper)
Auto Tracking:
Object auto tracking(Person/Vehicle), Target lock tracking
Ethernet:
Metal shielded RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
None
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Video Quality Adjustment:
Bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast (128 user) Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour,LLDP, SRTP
Security:
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device certificate(Hanwha Techwin Root CA) Cyber security assuarance program UL CAP(UL 2900-1)
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, +more
Web Viewer:
None
Edge Storage:
Micro SD/SDHC/SDXC 2slot 1TB
RAM:
4GB RAM, 512MB Flash
Operating Temperature / Humidity:
-40°C to +55°C /
Storage Temperature / Humidity:
-50°C~+60°C /
Certification:
IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9)
Input Voltage:
HPoE(IEEE802.3bt, Class6, Type3, Injector included)
Power (Max:
Typical 20W, Max 42W
Color / Material:
White, Black / Aluminum+Polycarbontate
RAL Code:
White: RAL9003 / Black: RAL9005
Product dimensions / weight:
Ø184.9x318.8mm(7.28x12.55") / 5.4Kg(11.90lb)
Detect (25PPM/ 8PPF:
Wide: 59.5m(195.3ft) / Tele: 2340.4m(7678.4ft)
Observe (63PPM/ 19PPF:
Wide: 23.8m(78.1ft) / Tele: 936.2m(3071.4ft)
Recognize (125PPM/ 38PPF:
Wide: 11.9m(39.1ft) / Tele: 468.1m(1535.7ft)
Identify (250PPM/ 76PPF:
Wide: 6.0m(19.5ft) / Tele: 234.0m(767.8ft)
Product Type:
PTZ
Connectivity:
Wired
Features:
WDR
Night Vision:
IR
Power Type:
PoE++
PoE Class:
6
Form Factor:
PTZ
IP Rating:
IP66, NEMA 4X
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
3m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
11.9
PTZ Range:
360˚ Endless
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
5-Year Warranty
Poe Power:
PoE++ (802.3bt)
Ir Lowlight:
IR
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Lens:
Type DC auto iris
Camera:
Title Displayed up to 85 characters
Ethernet Rate:
Metal shielded RJ-45(10/100BASE-T)
Application:
Programming ONVIF Profile S/G/T
Interface:
SUNAPI(HTTP API)
Memory:
4GB RAM, 512MB Flash
Storage:
Temperature / Humidity -50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing)
