Imaging Device:
1/2" 2MP CMOS
Effective Pixels:
1937(H)x1097(V)
Min. Illumination:
Color: 0.01Lux(F1.5, 1/30sec) BW: 0Lux(IR LED)
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
Focal Length (Zoom Ratio:
6~222mm(37x) zoom
Max. Aperture Ratio:
F1.5(Wide)~F4.6(Tele)
Angular Field of View:
H: 59.3°(Wide)~1.9°(Tele) / V: 35.8°(Wide)~1.1°(Tele)
Min. Object Distance:
1.5m(3.28ft)
Focus Control:
Oneshot AF
Lens Type:
DC auto iris
Pan Range:
360˚ Endless
Pan Speed:
Preset: 400˚/sec, Manual: 0.024˚/sec ~ 250˚/sec
Tilt Range:
190˚(-5˚~185˚)
Tilt Speed:
Preset: 300˚/sec, Manual: 0.024˚/sec ~ 250˚/sec
Sequence:
Preset, Swing, Group, Trace, Tour, Auto Run, Schedule
Preset Accuracy:
±0.2˚
Azimuth:
Support
Auto Tracking:
Support
IR Viewable Length:
350m(1,148.29ft)
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
150dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, rectangular zones
Privacy Masking:
24ea, rectangular zones - Color: Grey/Green/Red/Blue/Black/White - Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror
Analytics:
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection
Serial Interface:
RS-485 (multiple protocols)
Alarm Inputs/Outputs:
Input 4ea / Output 2ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output PTZ Preset
Audio In:
Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max.output level: 1Vrms
Ethernet:
RJ-45(10/100BASE-T), SFP(Optional)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Resolution:
1920x1080 (up to 640x360 min)
Max. Framerate:
60fps H.265/H.264, 30fps MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Video Quality Adjustment:
Bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast Multiple streaming (Up to 10 profiles)
Audio Compression:
G.711, G.726, AAC-LC
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SRTP, LLDP
Security:
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP)
Edge Storage:
SD/SDHC/SDXC 1slot 256GB
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Web Viewer:
Support OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Recommended brower : Google Chrome Supported broswer: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari (Mac OS X only)
RAM:
1024MB RAM, 256MB Flash
Operating Temperature / Humidity:
-50°C~+55°C (-122°F~+131°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C~+60°C (-122°F~+140°F) / Less than 90% RH
Certification:
IP66, IK10
Input Voltage:
24VAC
Power (Max:
24VAC: Max 90W
Color / Material:
Body: Ivory / Plastic, Head: Black / Plastic
Product dimensions / weight:
Ø236.9x407.7mm(9.33x16.05"), 7.1Kg(15.65 lb)
Hanging mount(Dome:
SBP-303HF(SFP)
Product Type:
PTZ
Night Vision:
Thermal
PTZ Range:
360˚ Endless
Housing Color:
White
