Hanwha XND-6081REV 2MP Vandal-Resistant Dome IP Camera

Hanwha XND-6081REV 2MP Vandal-Resistant Dome IP Camera

The Hanwha XND-6081REV is a robust 2MP indoor dome camera engineered for high-security environments requiring durability and advanced surveillance capabilities. With its vandal-resistant design (IK10 rated), motorized varifocal lens, and integrated PoE extender, this camera delivers flexible deployment options for institutional and commercial installations.

Key Features

• 2MP 1920x1080 resolution with 60fps H.265/H.264 streaming
• 2.8–12mm motorized varifocal lens (4.3x zoom) with auto iris
• 164ft IR range for reliable night-vision coverage
• 150dB Wide Dynamic Range (WDR) with HLC and SSDR backlight compensation
• IK10 vandal-resistant and IP52-rated dome enclosure
• Integrated PoE+ input and PoE output for extended camera chains
• Dual SD/SDHC/SDXC card slots (up to 512GB) for edge recording
• Advanced analytics: motion detection, face detection, digital auto-tracking, loitering, tampering, defocus, and fog detection
• Business intelligence: people counting, queue management, heatmap
• Bi-directional audio with selectable mic/line input and line output
• Digital image stabilization with built-in gyro sensor
• WiseStream II smart codec for bandwidth optimization
• Hallway view (90°/270° rotation) and 32 privacy masking zones

Technical Highlights

The XND-6081REV combines optical and digital capabilities for demanding surveillance scenarios. Its 119.5° wide-angle field of view and 27.9° telephoto reach enable comprehensive coverage with precise zoom capability. The camera identifies subjects at 49ft (telephoto) and recognizes faces at 101ft, supporting professional security operations. Minimum illumination of 0.015 Lux in color mode ensures visibility in low-light conditions, while IR extends surveillance into complete darkness.

Advanced video processing includes defog, lens distortion correction (LDC), and motion-compensated noise reduction (SSNRV). The 150dB WDR handles extreme contrast scenes typical of lobbies, entrances, and mixed indoor/outdoor zones. Multiple codec support—H.265, H.264, and MJPEG—accommodates varied network conditions, while WiseStream II dynamically adjusts bitrate to reduce storage demands without sacrificing image quality.

Built-in analytics detect intrusion patterns, loitering behavior, directional movement, and tampering attempts. Sound classification and audio detection enable audio-triggered alerts. The integrated PoE extender (12.95W at 80 meters over CAT5/5E) simplifies daisy-chaining multiple cameras in extended infrastructure.

Applications

Ideal for lobbies, corridors, retail environments, educational facilities, and secure areas requiring tamper-proof surveillance. The combination of zoom capability, analytics, and robust construction supports both access point monitoring and wide-area observation.

Karl Wilson

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The XND-6081REV targets institutional buyers needing dependable 2MP coverage with integrated intelligence. Its IK10 rating and motorized lens justify selection for unattended or semi-public spaces where camera protection is critical. The on-board PoE extender and dual SD slots reduce infrastructure complexity—particularly valuable in retrofit scenarios lacking centralized NVR capacity.

WiseStream II and multi-codec flexibility ease integration into mixed-vendor systems. The 60fps capability across all resolutions supports smooth motion analysis and forensic review. Primary consideration: the 2MP resolution and 4.3x optical zoom suit medium-distance identification; environments requiring long-range facial recognition may benefit from higher MP sensors or IP-camera clusters.
