Hanwha TNM-3620TDY 2MP QVGA Thermal Bi-Spectrum Fixed Lens Indoor/Outdoor IP Camera with AI Engine

The Hanwha TNM-3620TDY 2MP QVGA Thermal Body Temperature Network Camera with AI Engine represents a significant leap forward in the realm of security and health monitoring technologies. At its core, this advanced thermal imaging solution is designed to deliver high-resolution 2-megapixel visuals, complemented by a QVGA thermal imaging component that ensures precise temperature measurements. This dual-capacity enables the device to not only identify individuals with elevated body temperatures in real-time but also to do so with an exceptional level of accuracy, courtesy of its integrated artificial intelligence engine. The camera's AI capabilities enhance its performance by distinguishing between human subjects and other heat sources, thereby minimizing false alarms and ensuring reliable data for safety protocols.

Beyond its technical prowess, the Hanwha TNM-3620TDY camera is engineered with versatility and efficiency in mind. Its robust design makes it suitable for both indoor and outdoor environments, ensuring operational integrity in diverse settings. The camera also features state-of-the-art connectivity options, including both wired and wireless capabilities, allowing for seamless integration into existing security networks. Moreover, the device's power flexibility, supporting both AC and DC power sources along with Power over Ethernet (PoE), ensures easy installation and maintenance. The camera's sophisticated thermal detection system is further complemented by its wide-angle lens, providing comprehensive coverage and ensuring that no area goes unmonitored. With these features, the Hanwha TNM-3620TDY not only offers an unparalleled monitoring solution but also a tool that significantly contributes to public health and safety.

Key Features:

• Thermal Imaging: The TNM-3620TDY boasts a thermal resolution of up to 320 x 240 pixels, enabling it to detect body temperature variances effectively. This technology is crucial for identifying individuals with elevated body temperatures, a key aspect of health and safety in various environments.

• Visible Camera: Complementing the thermal imaging, a 2MP visible camera with a resolution of up to 1945 x 1109 pixels provides detailed color imaging, allowing for easy identification and context awareness.

• Dual Lenses: This camera combines an uncooled bolometer thermal lens and a 2MP CMOS visible lens with a 4mm fixed focal length, providing a comprehensive view of your environment.

• AI-Driven Analytics: Utilize advanced analytics including defocus detection, directional detection, motion detection, enter/exit monitoring, tampering detection, and virtual line crossing to enhance security and situational awareness.

• Digital Noise Reduction: Benefit from SSNRV technology for reduced noise and improved image clarity, ensuring accurate temperature measurement.

• Digital Image Stabilization: The built-in gyro sensor provides image stabilization, delivering clear and steady visuals, even in challenging conditions.

• Backlight Compensation: Enjoy a variety of compensation techniques, including BLC (Backlight Compensation), HLC (Highlight Compensation), WDR (Wide Dynamic Range), and SSDR (Samsung Super Dynamic Range), to optimize image quality in various lighting scenarios.

• Night Time Viewing: Automatic ICR (Infrared Cut Filter Removal) ensures seamless day-to-night transitions, while WiseStream II and advanced video compression technologies optimize bandwidth and storage usage.

• Power Supply: The camera can be powered via PoE (IEEE802.3af, Class4), ensuring easy and efficient installation.

• Operating Conditions: Designed to operate in temperatures ranging from 14°F to 131°F, the TNM-3620TDY is suitable for a wide range of environments.

• On-Board Storage: A microSD/SDHC/SDXC slot is available for local storage options.

Compatibility:

The Hanwha TNM-3620TDY is designed to seamlessly integrate with various surveillance systems, making it versatile and compatible with your existing infrastructure. Refer to the product manual and system requirements for specific compatibility details.

Specifications:

• Resolution:
  • Thermal: Up to 320 x 240
  • Visible: Up to 1945 x 1109
• Lenses:
  • Thermal: Uncooled Bolometer, 4.7" Fixed
  • Visible: 1/2.8" 2MP CMOS, 4mm Fixed
• Angular Field of View (Thermal):
  • Horizontal: 50°
  • Vertical: 36.4°
  • Diagonal: 65.3°
• Angular Field of View (Visible):
  • Horizontal: 87.6°
  • Vertical: 46.4°
  • Diagonal: 104.5°
• Analytics: Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line
• Digital Noise Reduction: SSNRV
• Digital Image Stabilization: Stabilization Support (built-in gyro sensor)
• Backlight Compensation: BLC, HLC, WDR, SSDR
• Night Time Viewing: Auto(ICR)
• Video Compression: WiseStream II/H.265/H.265/ H.264/ JPEG (MJPEG)
• Audio Compression: G.711 u-law /G.726, G.726(ADPCM) 8KHz, G.711
• Power Supply: PoE(IEEE802.3af, Class4)
• Operating Conditions: 14°F to 131°F
• On-Board Storage: microSD/SDHC/SDXC slot

Package Contents:

• Hanwha TNM-3620TDY 2MP QVGA Thermal Body Temperature Network Camera with AI Engine
• Mounting hardware for easy installation
• Detailed user manual and documentation

Equip your surveillance system with the Hanwha TNM-3620TDY to monitor body temperature effectively and ensure the safety of your premises. This advanced network camera is a powerful tool that combines thermal imaging, AI analytics, and advanced features to safeguard your environment.
