Hanwha SHD-1600FPW Plenum In-Ceiling Housing
The SHD-1600FPW is a plenum-rated in-ceiling housing engineered for seamless integration of Hanwha IP cameras into suspended drop-ceiling environments. This white flush-mount enclosure delivers code-compliant camera concealment without sacrificing accessibility or cable management — a practical requirement in corporate offices, healthcare facilities, retail spaces, and other regulated indoor environments where plenum-rated materials are mandatory.
Key Features
- Plenum-rated construction: Complies with building fire safety codes (NFP 101 and building standards), meaning you won't trigger re-inspection or remediation costs if your authority having jurisdiction audits your ceiling cavity wiring and materials.
- Flush-mount design: Sits flush against drop-ceiling tile, minimizing visual protrusion and maintaining a finished, professional appearance — no pendant-style protrusion that draws attention.
- Tile-thickness compatibility (5–70mm): Accommodates virtually any standard suspended ceiling tile, reducing custom fabrication and installation workarounds on retrofit projects.
- Dual conduit ports (19.1mm M25 and 12.7mm M20): Two different knockout sizes let you route cable flexibly — use 3/4" conduit for denser installations or 1/2" for single-run feeds without forcing adapters.
- Aluminum enclosure with polycarbonate cover: Lightweight (1200g / 2.65 lb) yet rigid enough to hold camera weight and vibration without sagging, and polycarbonate resists impact during maintenance access.
- Compact circular footprint (Ø234 × 123.24mm): Fits within a single 24" × 24" drop-ceiling tile opening or integrates into modular tile grids without extensive cutting.
- RAL9003 white finish: Standard office color blends with white or light-gray suspended ceilings, avoiding the dark shadow effect of unfinished metal housings.
Camera Compatibility
The SHD-1600FPW is designed to integrate with Hanwha's modular in-ceiling camera lineup, including the PNV-9080R, XNF series (9010RV, 8010R, 8010RV), XND series (6085, 6085V, C9083RV, C8083RV, C7083RV, C6083RV), and XNV series (C9083R, C8083R, C7083R, C6083R, 6085, 6120, 6120R, 8080R, 6080R, 6080, L6080R, L6080). Verify your specific camera model with installation documentation before ordering, as mounting points and connector routing vary across the modular range.
Installation Context
In-ceiling housings matter most when you need both regulatory compliance and visual discretion. Plenum-rated materials prevent toxic smoke and flame spread if a fire occurs in the ceiling cavity — a code requirement in most U.S. commercial buildings and many international jurisdictions. The SHD-1600FPW eliminates the need for expensive custom metal or retrofit shielding, and its tile-thickness range eliminates the frustration of adapters or rework when ceiling depth varies across a large facility. For network-connected surveillance systems, pair this housing with appropriate PoE switch infrastructure to ensure reliable power and data delivery to the mounted camera.
Deployment Considerations
Verify plenum-compliance documentation aligns with your local building codes before installation — standards vary by jurisdiction (NFPA 101, IBC, CEC). Confirm camera lens angle and mounting depth fit within the housing's internal cavity; some wide-angle or motorized lens variants may require repositioning or spacers. Test cable routing and conduit knockout placement during mock-up — awkward conduit angles can complicate future service calls. For larger deployments across multi-floor buildings, standardize on either M25 or M20 conduit throughout to simplify spares inventory and technician training.
Frequently Asked Questions
Q: Does the SHD-1600FPW come with mounting brackets or hardware?
A: The housing is designed for direct ceiling tile mounting. Verify all necessary brackets and fasteners are included in the package before installation; specific hardware details are documented in the installation guide.
Q: Can I use the SHD-1600FPW in a vented plenum (HVAC return air space)?
A: Yes — plenum-rated materials meet fire safety codes for both sealed and HVAC plenum spaces. Confirm local code requirements before deployment, as some jurisdictions impose additional restrictions on certain material types in active air-return cavities.
Q: What camera models are compatible with the SHD-1600FPW?
A: The housing supports Hanwha's modular in-ceiling camera family, including PNV-9080R, XNF, XND, and XNV series models. Check the camera's installation guide or contact the vendor to confirm mounting compatibility before purchase.
Q: Is the polycarbonate cover UV-resistant?
A: Polycarbonate covers are designed for indoor ceiling environments. If exposed to direct, prolonged sunlight (atrium installations), verify compatibility with your VAR or systems integrator, as extended UV exposure may affect clarity over time.
Q: Can I fit both conduit sizes on the same housing?
A: Yes — the SHD-1600FPW includes separate knockout options for M25 (19.1mm) and M20 (12.7mm) conduit, allowing flexible cable routing on a single housing unit.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The SHD-1600FPW solves a real compliance and logistics headache: plenum-rated in-ceiling camera housing without custom fabrication or retrofit rework. On multi-floor commercial builds, I've watched crews waste time sourcing compliant materials or waiting for AHJ approval on non-standard setups. This housing eliminates that friction, and the 5–70mm tile-thickness range means you won't be cursing retrofit depths halfway through a 100-camera rollout.
Key Deployment Wins:
- Plenum-rated material (NFP 101 compliant): No re-inspection delays or remediation costs if your local authority questions ceiling cavity materials — code sign-off is built in, saving 2–4 weeks of back-and-forth on large projects.
- Dual conduit options (M25 and M20): Flexibility in cable routing means you can standardize on 3/4" conduit in dense installations or switch to 1/2" for simpler runs without forcing adapters and rework.
- Compact footprint (Ø234mm) and 1200g weight: Mounts directly into a single 24" × 24" ceiling tile without load-bearing concerns or structural reinforcement — critical in retrofit work where ceiling grids are often marginal.
Deployment Considerations:
- Verify your specific Hanwha camera model's mounting depth and connector routing against the housing cavity before order — some wide-angle or motorized variants need mock-up testing.
- Plenum codes vary by jurisdiction (IBC, CEC, NFPA 101); confirm your local AHJ explicitly approves this material type before scaling across the site.
- On large builds, standardize conduit size (M25 vs. M20) across all housings to avoid splitter confusion during service calls and bulk spare inventory.
This housing is purpose-built for regulated commercial ceilings — hospitals, financial centers, federal buildings, and retail chains where codes are non-negotiable and surprises from the fire marshal are career-limiting. If you're deploying Hanwha in-ceiling cameras and your ceiling is above a plenum space, this is your standard solution, not an afterthought.
