Imaging Device:
1/2.8" CMOS
Resolution:
1920×1080
Max. Framerate:
30fps
Min. Illumination:
0.03 Lux color / 0 Lux IR
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
Focal Length (Zoom Ratio:
3.6mm fixed focal
Max. Aperture Ratio:
F2.0
Angular Field of View:
H: 94.8˚ / V: 49.3˚ / D: 114.3˚
Min. Object Distance:
0.5m(1.64ft)
Focus Control:
Fixed
Pan / Tilt / Rotate Range:
±5° / 0°~67° / ±90°
Camera Title:
Displayed up to 15 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
SSNR
Motion Detection:
4ea, polygonal zones
Privacy Masking:
6ea, rectangular zones
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90˚/270˚)
Analytics:
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line
Alarm Triggers:
Analytics, Network disconnect
Alarm Events:
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers
Audio In:
Selectable(mic in/line in/built-in mic)
Audio Out:
Line out, Max.output level: 1Vrms
IR Viewable Length:
15m(49.21ft)
Ethernet:
Metal shielded M12 (10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, +more
Smart Codec:
WiseStreamⅡ
Video Quality Adjustment:
H.264/H.265 bitrate, MJPEG quality control
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(6 users) / Multicast Multiple streaming (Up to 3 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
Security:
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access Log 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, +more
Edge Storage:
Micro SD/SDHC/SDXC 1slot 128GB
RAM:
512MB RAM, 256MB Flash
Operating Temperature / Humidity:
-30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Certification:
IP66, IK10, NEMA4X EN55011:2009+A1:2010, EN50581:2012,EN50121-3-2:2015, EN61000-4-2:2009, EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014 EN61000-4-6:2009, EN50155:2017 EN45545-2, NFPA130, BSS7239, E-mark
Input Voltage:
PoE(IEEE802.3af, Class3)
Power (Max:
PoE: Max 6.70W, typical 5.00W
Color / Material:
Ivory / Aluminum
Product dimensions / weight:
98.9x52.0x100.0mm(3.89x2.05x3.94"), 295g(0.65 lb)
Detect (25PPM/ 8PPF:
35.3m(115.84ft)
Observe (63PPM/ 19PPF:
14.1m(46.33ft)
Recognize (125PPM/ 38PPF:
7.1m(23.17ft)
Identify (250PPM/ 76PPF:
3.5m(11.58ft)
Product Type:
Dome
Night Vision:
Thermal
Housing Color:
White
Environment Rating:
Outdoor
Poe Power:
PoE (802.3af)
Wdr:
WDR
Ir Lowlight:
IR
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
3.6 mm
Camera:
Title Displayed up to 15 characters
Ethernet Rate:
Metal shielded M12 (10/100BASE-T)
Application:
Programming ONVIF Profile S/G/T
Memory:
512MB RAM, 256MB Flash
Operating Temp:
/ -30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
Storage:
Temperature / Humidity -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Frame Rate:
30fps
Power:
PoE
IP Rating:
IP66
Impact Rating:
IK10
Resolution Pixels:
1920x1080
Brand:
Hanwha
MPN:
QNV-6024RM
Type:
Expansion Module
Connectivity:
Ethernet
