Imaging Device:
1/2.8" CMOS x 4CH
Resolution:
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.05lux(F1.6,30 IRE) BW: 0Lux(IR LED on)
Focal Length (Zoom Ratio:
3.2~10mm(3.1x) motorized varifocal
Max. Aperture Ratio:
F1.6(Wide)~F2.9(Tele)
Angular Field of View:
H: 109.0°(Wide)~33.2°(Tele), V: 57.4°(Wide)~18.7°(Tele), D: 132.0°(Wide)~38.0°(Tele)
Min. Object Distance:
0.5m(1.64ft)
Focus Control:
Simple focus
Lens Type:
DC auto iris
Pan / Tilt / Rotate Range:
Remote adjustment (Max. 200cycles) 0~360˚ / 30~80˚ / 0~90˚
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support (built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, polygonal zones - Color: Grey, Green, Red, Blue, Black, White - Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation:
Flip, Mirror
Analytics:
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection
Alarm Inputs/Outputs:
Input 1ea / Output 1ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC at event triggers Alarm output Handover
Audio In:
Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Audio Out:
Line out, Max.output level: 1Vrms
Ethernet:
Metal shielded RJ-45(10/100/1000BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
G.711 u-law /G.726 G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Video Quality Adjustment:
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP
Security:
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA)
Application Programming Interface:
ONVIF Profile S/T SUNAPI(HTTP API) Wisenet open platform
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 4slot 256GB(each CH)
RAM:
5GB RAM, 1280MB Flash
Operating Temperature / Humidity:
-40°C~+55°C(-40°F~+131°F) / Less than 90% RH
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / Less than 90% RH
Certification:
IP66, IK10, NEMA4X
Input Voltage:
HPoE(IEEE802.3bt, Class6, Type3, Injector included), 12VDC
Power (Max:
PoE: Max. 42 W, Typical 30 W 12VDC: Max. 38 W, Typical 28.2 W
Color / Material:
White / Aluminum
RAL Code:
RAL9003
Product dimensions / weight:
Ø315x145.9 mm(12.40"x5.74") / 5.2 kg(11.5lb)
Compatible Conduit hole / Gangbox:
3/4"
Hanging mount(Dome:
SBP-317HMW
Detect (25PPM/ 8PPF:
Wide: 27.4m(89.9ft) / Tele: 128.8m(422.6ft)
Observe (63PPM/ 19PPF:
Wide: 62.5m(35.9)ft) / Tele: 51.5m(169.0ft)
Recognize (125PPM/ 38PPF:
Wide: 5.5m(18.0ft) / Tele: 25.8m(84.5ft)
Identify (250PPM/ 76PPF:
Wide: 2.7m(9.0)ft) / Tele: 12.9m(42.3ft)
