Hanwha AT-IE220-6GHX-980 Industrial PoE++ Switch
The Hanwha AT-IE220-6GHX-980 is a compact, industrial-grade managed network switch engineered for mission-critical IP surveillance, thermal imaging, and IoT deployments in demanding environments. Built for reliability and performance, this 6-port switch combines high-power PoE delivery with fanless operation and DIN rail integration, making it ideal for distributed camera systems, outdoor installations, and edge computing applications where space and power efficiency are paramount.
Key Features
- 4 x 1GbE (RJ-45) Gigabit Ethernet ports with mixed PoE power delivery
- 2 x 1/10G SFP+ uplink ports for high-speed backbone connectivity
- 180W maximum PoE power budget supporting simultaneous multi-camera deployments
- 2 x PoE++ (90W) ports and 4 x PoE+ (30W) ports for PTZ cameras, thermal sensors, and LED illuminators
- 48 Gbps non-blocking switching fabric with 35.7 Mpps forwarding rate
- Fanless aluminum chassis for silent, maintenance-free operation
- IP30 protection rating for industrial and outdoor installations
- Compact form factor: 65 x 137 x 155 mm (2.56 x 5.39 x 6.12 in)
- DIN rail mounting for standard 19-inch cabinet integration
- 37–57V DC input compatible with redundant power supplies
- Ultra-low power consumption: 17.4W maximum
Technical Highlights
Ports & Connectivity: The switch provides 6 total ports optimized for mixed-speed deployments. Four Gigabit Ethernet ports deliver flexible power delivery: 2 ports rated for PoE++ at 90W each (supporting ultra-high-power devices), and 4 ports rated for PoE+ at 30W each. Two 1/10G SFP+ ports enable high-speed uplinks to core network infrastructure or redundant paths, supporting fiber connectivity for long-distance runs.
Performance & Throughput: The 48 Gbps switching fabric and 35.7 Mpps forwarding rate deliver wire-speed, non-blocking performance across all ports. This architecture eliminates congestion and latency spikes critical for real-time HD/4K video streams, multi-sensor thermal data, and latency-sensitive IoT applications.
Power Management: With a 180W aggregate PoE budget, the AT-IE220 simultaneously powers demanding edge devices—PTZ cameras, thermal imaging systems, high-brightness LED illuminators, and industrial sensors—without daisy-chaining or external power injectors. The 17.4W device power consumption ensures efficient operation even in power-constrained deployments.
Design & Durability: The fanless, sealed aluminum/sheet metal enclosure with IP30 protection handles vibration, temperature fluctuation, and dust-prone industrial environments. Lightweight construction (1.57 kg DIN rail mount) and compact dimensions enable flexible installation in tight spaces, while 37–57V DC input supports wide-input-range power supplies for harsh field conditions.
Applications
- Multi-camera surveillance networks in manufacturing, transportation, and logistics facilities
- Thermal imaging systems for predictive maintenance and perimeter security
- Distributed edge computing and IoT sensor networks in industrial settings
- Outdoor and underground installations requiring IP-rated, fanless operation
- Redundant network architectures with fiber SFP+ uplinks to core switches
Karl WilsonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The AT-IE220-6GHX-980 strikes an optimal balance between port density, PoE capacity, and thermal efficiency for mid-scale industrial surveillance deployments. The dual PoE++ ports (90W each) distinguish this model from basic PoE+ switches, enabling single-cable powering of power-hungry PTZ cameras and multi-sensor thermal units without auxiliary power injectors. The 48 Gbps switching fabric ensures that high-bitrate 4K cameras and concurrent thermal streams do not contend for bandwidth, critical in latency-sensitive security and monitoring scenarios.
For integrators designing distributed networks across multiple buildings or outdoor perimeters, the dual 1/10G SFP+ ports provide flexible uplink options—fiber runs for EMI immunity, or copper for short-distance core connectivity. The fanless, sealed enclosure and wide 37–57V DC input tolerance make this switch suitable for unattended outdoor cabinets, marine installations, and environments subject to temperature cycling. Total power draw of 17.4W is minimal, reducing operational cost and enabling solar/battery-backed deployment scenarios.
This switch is best suited for customers requiring industrial-grade reliability, compact form factor, and high per-port PoE capacity in a single managed device.
