Hanwha AT-IE220-10GHX-980 Industrial PoE++ Switch
The Hanwha AT-IE220-10GHX-980 is a compact, industrial-grade managed network switch engineered for demanding edge deployments in harsh environments. Combining 8 Gigabit Ethernet PoE ports with dual 1/10G SFP+ uplinks and a robust 240W PoE power budget, this fanless switch delivers reliable connectivity and flexible power delivery for mission-critical surveillance, IoT, and industrial applications.
Key Features
- 8 × Gigabit Ethernet (RJ-45) ports with mixed PoE+/PoE++ support
- 2 × 1/10G SFP+ uplink ports for high-speed backbone connectivity
- 240W total PoE power budget with flexible port allocation
- 56Gbps switching fabric and 41.7 Mpps forwarding rate
- Fanless operation for noise-free, maintenance-free deployment
- Compact DIN rail form factor: 65 × 137 × 155 mm
- Aluminum/sheet metal enclosure with IP30 protection rating
- Ultra-low power consumption: 18.5W maximum
- Wide input voltage range: 37–57V DC
PoE Power Distribution
The AT-IE220-10GHX-980 offers granular PoE flexibility across all 8 copper ports. Eight ports deliver PoE+ (30W), with four of those ports also supporting HI-PoE (60W) for mid-range devices, and two dedicated ports capable of full PoE++ (90W) for power-hungry edge analytics appliances, PTZ cameras, and advanced IoT equipment. This mixed-mode architecture maximizes device compatibility while maintaining power budget efficiency.
Technical Highlights
The dual SFP+ uplink ports support both 1Gbps and 10Gbps connections, enabling flexible network topology designs and future-proof backbone integration without chassis upgrades. The 56Gbps switching fabric with 41.7 Mpps forwarding rate ensures non-blocking performance across all ports, critical for real-time surveillance and latency-sensitive applications. Fanless design eliminates moving parts, reducing operational costs and failure points in remote locations. The compact form factor and DIN rail mounting standard integrate seamlessly into industrial cabinets and edge computing environments.
Applications
Ideal for industrial video surveillance networks, distributed IoT sensor deployments, smart city infrastructure, factory automation, and critical infrastructure monitoring where compact size, low power consumption, and high PoE capacity are essential. Suitable for outdoor cabinets, telecom enclosures, and confined spaces where fanless operation and minimal heat dissipation (63.3 BTU/hr) are required.
Karl WilsonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The AT-IE220-10GHX-980 is purpose-built for industrial edge networking where reliability and efficiency outweigh raw throughput. The 240W PoE budget paired with mixed PoE+/PoE++ capability makes this switch exceptionally valuable for heterogeneous deployments mixing legacy PoE devices with newer 90W edge appliances. The fanless design and 18.5W power draw make it ideal for solar or battery-backed remote sites, while the IP30 rating and aluminum enclosure withstand moderate environmental stress.
The dual SFP+ ports eliminate the need for separate uplink cards and provide long-distance trunk connectivity via fiber. For organizations deploying distributed surveillance or IoT infrastructure across branch offices or industrial sites, this switch delivers the right balance of power delivery, performance, and operational simplicity at the edge.
