Viking E-60 Plate in Oil Rubbed Bronze - PNL60-BN

Viking Electronics PNL60-BN E-60 Series Replacement Faceplate in Oil Rubbed Bronze

Overview

The PNL60-BN is a replacement faceplate designed specifically for Viking Electronics E-60 Series entry phones. If an existing installation has a damaged front panel or you need to reface a unit to match an oil rubbed bronze finish scheme, the PNL60-BN drops in as a direct swap. It ships with color-matched screws and an LED light pipe so the indicator light remains fully functional after the swap — no sourcing separate hardware. The faceplate is cut from 18-gauge 304 stainless steel, which holds up to surface wear and casual impact without deforming or corroding. At 123.8mm × 125.4mm × 4.3mm, it matches the original panel geometry exactly.

Compatibility

The PNL60-BN is compatible exclusively with the Viking E-60 Series entry phones — including VoIP variants such as the E-60-BN-IP-EWP. It is not a universal faceplate; do not attempt to fit it on E-10, E-30, or other Viking series panels. If your installed unit is an E-60 Series phone in a double-gang bronze configuration, this is the correct replacement part. Confirm your existing phone's series designation before ordering — the mounting pattern and LED light pipe geometry are specific to the E-60 platform.

Installation Notes

Mounting uses #6-32 × 1.25" flat-head screws driven with a 5/64" hex (Allen) driver — include that bit in your toolkit before arriving on site. The color-matched screws included in the kit maintain the oil rubbed bronze appearance at the fastener points. 18-gauge 304 stainless steel panels can crack if overtorqued; drive fasteners snug, not tight. The LED light pipe is pre-aligned for the E-60 Series aperture — seat it fully before securing the faceplate to avoid misalignment with the indicator lens.

What's in the Box

• 1x PNL60-BN oil rubbed bronze replacement faceplate (18-gauge 304 stainless steel)
• Color-matching screws (#6-32 × 1.25" flat head)
• 1x LED light pipe
