Viking Electronics PNL40-BN Replacement Faceplate

Overview

The Viking Electronics PNL40-BN is a replacement faceplate designed for the Viking E-40 series communication devices. It features an Oil Rubbed Bronze finish and is constructed from durable 18-gauge 304 stainless steel, providing a robust aesthetic for commercial or institutional environments. The integrated push-button switch is sealed to an IP67 rating, ensuring protection against dust and water ingress, making it suitable for exposed locations. This faceplate is intended for use with specific Viking E-40 models, offering a direct replacement for damaged or outdated units.

Compatibility

This PNL40-BN faceplate is specifically designed as a replacement for Viking Electronics E-40 series communication units. It is compatible with the base E-40 unit and requires a single gang electrical box or a Viking VE-3x5 mounting box for installation. It is not compatible with other Viking product lines or third-party devices.

Installation Notes

Installation requires a standard single gang electrical box or the Viking VE-3x5 box. The faceplate dimensions are 4.875" x 3.125" x 0.18". The push-button switch is internally sealed to IP67 standards. The unit is telephone line powered, requiring a minimum of 18V DC and 20mA, and supports a ring voltage of 25V AC RMS minimum. The CPC disconnect time must be a minimum of 300ms. Operating temperature range is -30°F to 150°F with humidity from 5% to 95% non-condensing.
