Sensor Type:
2.1MP/1080p 1/2.8" CMOS sensor
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.05 lux (color)
Focal Length:
2.8mm
IR Distance:
80' range Smart IR™
Lens Type:
Fixed Lens
Vertical Field of View (VFOV:
62°
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC, up to 1TB
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Email, FTP server, SD card recording
Privacy Zones:
16 programmable privacy masks
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter Speed:
Off, x10, x2, x3, x4, x5, x6, x7.5
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
CBR/VBR H.264, H.265, controllable frame rate
IP:
IPv4
LAN:
RJ45 (10/100Base-T)
Network resolution:
2.1MP/1080p, 720p, VGA, D1, CIF
Network Web Viewer:
Chrome, Edge, Firefox, Safari on Windows/Mac/Linux
ONVIF conformant:
yes
Protocol:
Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security:
802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed:
Up to 30fps at all resolutions
Video Bitrate:
32Kbps~20Mbps
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
ONVIF compatible CMS, DW Spectrum, ExacqVision, Milestone
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
4.13" x 2.38" (105 x 60.7 mm)
Camera Weight:
0.79 lbs (0.36kg)
Housing:
Vandal Dome
Housing Color:
White
Vandal Rating:
IK10 Rated
IP Rating:
IP67
Materials:
Aluminum die-casting
American wire gauge (AWG:
80M, Cable type #18
Power (Max:
DC12V: max 3.7W, 308.3mA, PoE: max 5.5W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Max Resolution:
2.1MP/1080p
