Type:
Turret
Features:
Night Vision
Features:
Weatherproof
Frame Rate:
High
Sensor Type:
2.1MP/1080p 1/2.8" CMOS sensor
Max Resolution:
2.1MP/1080p
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.043 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
1945 (H) X 1109 (V)
Advanced Lens Features:
Auto focus, Motorized zoom, P-iris
Horizontal Field of View (HFOV:
93.6° ~ 34.1°
IR Distance:
100' range Smart IR™
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
19.2° ~ 51.8°
IVA license:
Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license:
Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Backlight compensation (BLC:
Yes
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC, up to 1TB
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, SD card recording
Privacy Zones:
16 programmable privacy masks
Shutter Mode:
Auto, Manual, Slow Shutter
Shutter Speed:
8 ~ 1/50000
Slow Shutter Speed:
Off, x15, x2, x3, x4, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR H.264
IP:
IPv4
Network resolution:
H.264/H.265: QFHD to CIF, MJPEG: 1280x1024 to 240p
Network Web Viewer:
Chrome, Edge, Firefox, Safari on Windows/Mac/Linux
Protocol:
Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security:
802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
32Kbps~20Mbps
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
DW Spectrum, ExacqVision, Milestone Systems
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
4.92" x 4.4" (125 x 112mm)
Camera Weight:
1.83 lbs (0.83kg)
Housing:
Vandal ball turret, Turret
Housing Color:
White
Vandal Rating:
IK10 Rated
IP Rating:
IP67
Materials:
Aluminum die-casting
American wire gauge (AWG:
Cable type #18
Power (Max:
DC12V: max 6.4W, 533.3mA, PoE: max 7.6W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Turret
Connectivity:
Wired
Power Type:
PoE
Resolution:
2MP
Night Vision:
IR
Environment Rating:
Outdoor
