Digital Watchdog DWC-MPF5Wi8TW 5MP IR Outdoor Dome IP Camera

Digital Watchdog DWC-MPF5Wi8TW 5MP Outdoor IR Dome Camera

The Digital Watchdog DWC-MPF5Wi8TW is a professional-grade 5MP outdoor dome camera engineered for comprehensive surveillance in demanding environments. Built with a 5MP 1/2.8" CMOS sensor and 8mm fixed lens, this camera delivers sharp, detailed imagery across expansive perimeters, parking lots, and building facades. Its vandal-resistant IK10-rated polycarbonate dome and IP66-rated aluminum housing ensure reliable performance in harsh weather conditions.

Key Features

• 5MP resolution with 2592 × 1944 pixel capture for exceptional detail
• 50-foot Smart IR™ night vision for 24/7 monitoring in complete darkness
• 8mm fixed lens with 37.8° horizontal field of view—ideal for targeted, long-range coverage
• True WDR 120dB wide dynamic range for backlit and high-contrast scenes
• IK10 vandal-resistant dome rated for high-impact environments
• IP66 weatherproof rating for rain, dust, and environmental exposure
• PoE-powered design with minimal 7.2W consumption for simplified deployment
• Dual-stream H.264/H.265 video compression with up to 30fps at all resolutions
• Smart DNR™ 3D noise reduction for cleaner low-light footage
• Micro SD/SDHC/SDXC local recording up to 1TB (FAT32)
• 16 programmable privacy masks for sensitive area protection
• Auto day/night switching with color mode (0.16 lux) and B/W mode (0.0 lux)

Technical Highlights

The DWC-MPF5Wi8TW operates reliably across -4°F to 122°F (-20°C to 50°C) environments and maintains 10–90% non-condensing humidity tolerance. Its motorized lens and auto white balance adapt to changing lighting conditions, while manual shutter control (1/15 to 1/32000) and slow-shutter modes optimize exposure in variable scenes. Motion detection and intelligent video analytics (IVA+ licensed) enable intrusion detection, line crossing, loitering, tailgating, direction tracking, and object-removal alerts. Dual audio I/O with G.711 compression supports two-way communication; dual 1-input/1-output alarm channels control external devices or record alerts.

Network integration is seamless via ONVIF conformance, supporting DW Spectrum® IPVMS, Genetec, Milestone, and ExacqVision platforms. IPv4 support includes DHCP, DNS, DDNS, NTP, HTTPS/TLS encryption, 802.1x authentication, and SNMPv3 monitoring. The camera streams H.264, H.265, or MJPEG formats at variable bitrates (32Kbps–20Mbps) across multiple resolutions.

Applications

Ideal for perimeter security, parking lot surveillance, building exterior monitoring, and critical infrastructure protection. The 8mm lens and 37.8° HFOV excel in focused coverage of distant zones where wide-angle capture is unnecessary. The IK10 vandal rating suits high-risk locations prone to tampering.

Ted Perry

The DWC-MPF5Wi8TW represents Digital Watchdog's commitment to rugged outdoor surveillance. Its combination of 5MP resolution, 50-foot IR range, and True WDR 120dB ensures performance in mixed-lighting perimeter deployments. The 8mm lens trades field of view for focused depth and telephoto capability—deploy this model where wide coverage is unnecessary but long-range detail matters.

The IK10 rating and IP66 sealing justify use in exposed or high-vandalism zones. PoE simplification and edge recording via microSD eliminate NVR dependency for smaller installations. IVA+ analytics enable pro-level behavioral detection without separate licensing infrastructure.

The 5-year warranty and broad CMS compatibility reinforce this as a solid mid-tier outdoor investment for enterprises prioritizing durability and remote monitoring.

Available in White.
